NetApp FAS2050 with 20 x 300Gb 15k SAS and 1x DS14-AT MK2 With 14x 1TB SATA
REQUEST A PRICE QUOTE:
NetApp FAS2050 with 20 x 300Gb 15k SAS and 1x DS14-AT MK2 With
14x 1TB
20Tb of Storage
NetApp FAS2050 with 2 x PSU
20 x 300Gb SAS 15k
1 x Controller
DS14-AT MK2 with 14 x 1TB, 2 x Controller, 2 x PSU
The NetApp FAS2050 is a scalable iSCSI / FC SAN / NAS storage appliance with up to 104TB capacity
The NetAppFAS2050 is ideal for specialised storage environments. The FAS2050 system provides great versatility with integrated block- and file-level data access, intelligent management software and advanced data-protection capabilities.
It can be supplied with either internal SAS or SATA drives. FAS2050’s are capable of running the full suite of NetApp software and can be used as primary or secondary storage for both block and file storage over Fibre Channel and Ethernet networks.
The FAS2050 is a cost effective system which has been designed to push the threshold of high storage density in a small space, increase connectivity options and improve manageability in the SMB market place. The FAS2050 has dual controllers and disk drives integrated into a single chassis and has lead offerings for iSCSI and Remote Office/Branch Office (ROBO) market segments.
With up to 15TB of integrated storage capacity and dual active controllers in a compact 4U form factor, the FAS2050 easily scales up to meet growing enterprise demands by simply adding up to six DS14mk4FC and/or DS14mk2AT expansion shelves. With this ability, the FAS2050 can scale up to 104 drives and 104TB of total storage.
FAS2050 is priced to compete in the mid market and offers exceptional value, especially when its built in data deduplication capabilities are taken into account.
Boot Log:
zugfas01> license
a_sis *******
cifs *******
flex_clone *******
iscsi *******
earstore_option *******
nfs *******
snaprestore *******
sv_ontap_pri *******
sv_ontap_sec *******
zugfas01> version
NetApp Release 7.3.2: Thu Oct 15 04:17:39 PDT 2009
zugfas01> sysconfig -a
NetApp Release 7.3.2: Thu Oct 15 04:17:39 PDT 2009
System ID: 0135035689 (zugfas01)
System Serial Number: 20008733 (zugfas01)
System Rev: G1
System Storage Configuration: Single Path
System ACP Connectivity: No Connectivity
slot 0: System Board 2198 MHz (System Board XIV H1)
Model Name: FAS2050
Part Number: 110-00048
Revision: H1
Serial Number: 817961
BIOS version: 3.0
Processors: 1
Processor ID: 0xf29
Microcode Version: 0x2f
Memory Size: 2048 MB
NVMEM Size: 256 MB of Main Memory Used
CMOS RAM Status: OK
Controller: B
slot 0: Dual 10/100/1000 Ethernet Controller G20
e0a MAC Address: 00:a0:98:0d:54:70 (auto-unknown-down)
e0b MAC Address: 00:a0:98:0d:54:71 (auto-unknown-down)
Device Type: Rev 6
memory mapped I/O base 0xd9600000, size 0x20000
memory mapped I/O base 0xd9620000, size 0x20000
I/O base 0x0000cfe0, size 0x20
memory mapped I/O base 0xd9640000, size 0x20000
memory mapped I/O base 0xd9660000, size 0x20000
I/O base 0x0000cfc0, size 0x20
memory mapped I/O base 0xd8000000, size 0x1000
I/O base 0x0000ffe0, size 0x20
memory mapped I/O base 0xd9000000, size 0x100000
prefetchable memory base 0xdb800000, size 0x800000
slot 0: FC Host Adapter 0a (QLogic 2432 rev. 2, L-port, <OFFLINE (hard)>)
Firmware rev: 4.4.0
Host Loop Id: 0
FC Node Name: 5:00a:098000:02b1fc
SFP Vendor: FINISAR CORP.
SFP Part Number: FTLF8524P2BNV
SFP Serial Number: PDK52HN
SFP Capabilities: 1, 2 or 4 Gbit
Link Data Rate: 1 Gbit
I/O base 0x0000ee00, size 0x100
memory mapped I/O base 0xd9200000, size 0x4000
slot 0: FC Host Adapter 0b (QLogic 2432 rev. 2, L-port, <OFFLINE (hard)>)
Firmware rev: 4.4.0
Host Loop Id: 0
FC Node Name: 5:00a:098100:02b1fc
SFP Vendor: FINISAR CORP.
SFP Part Number: FTLF8524P2BNV
SFP Serial Number: PDK54WD
SFP Capabilities: 1, 2 or 4 Gbit
Link Data Rate: 1 Gbit
I/O base 0x0000ef00, size 0x100
memory mapped I/O base 0xd9204000, size 0x4000
slot 0: SAS Host Adapter 0c (LSI Logic 1068E rev. B2, SAS, <UP>)
Firmware rev: 1.26.03.00
Base WWN: f:080c7b:2900000:00
Phy State: [0] Enabled, 3.0 Gb/s
[1] Enabled, 3.0 Gb/s
[2] Enabled, 3.0 Gb/s
[3] Enabled, 3.0 Gb/s
00.0 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y2YZ00009849RDH9)
00.1 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49L2H00009848WCCT)
00.2 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49HVP00009849P70R)
00.3 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49GGH00009848JLTN)
00.4 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y2WP00009848KE6H)
00.5 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y1WM00009849M63Z)
00.6 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y1WP00009849M6C5)
00.7 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y2M600009848H824)
00.8 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49LDA00009848JJXH)
00.9 : NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49L3C00009848H911)
00.10: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49LK100009848H92H)
00.11: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49KZT00009848JLY4)
00.12: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y1S300009848LP5D)
00.13: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y23F00009849M7QZ)
00.14: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y21X00009849M7U4)
00.15: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4XDNA00009848JF5P)
00.16: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y1VP00009849M64L)
00.17: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM49GG000009848KDP3)
00.18: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y1S700009848LPDF)
00.19: NETAPP X287_S15K5288A15 NA01 272.0GB 520B/sect (3LM4Y88N00009848KD88)
Shelf 0: ESAS Firmware rev. SAS A: — SAS B: 05
I/O base 0x0000df00, size 0x100
memory mapped I/O base 0xd9410000, size 0x4000
memory mapped I/O base 0xd9400000, size 0x10000
slot 0: ATA/IDE Adapter 0e (0x000001f0)
0e.0 STEC NACF256MM1U-B11 01/17/07 245MB 512B/sect (STI1M81608122133654)
I/O base 0x0000ffc0, size 0x8
I/O base 0x0000ffb8, size 0x4
I/O base 0x0000ffc8, size 0x8
I/O base 0x0000ffbc, size 0x4
I/O base 0x0000ffd0, size 0x10
memory mapped I/O base 0xd8001000, size 0x400
slot 1: Dual 10/100/1000 Ethernet Controller G20
e1a MAC Address: 00:15:17:77:bc:a0 (auto-unknown-down)
e1b MAC Address: 00:15:17:77:bc:a1 (auto-unknown-down)
Device Type: Rev 6, PBA D50228-005
memory mapped I/O base 0xd9800000, size 0x20000
memory mapped I/O base 0xd9820000, size 0x20000
I/O base 0x0000bfe0, size 0x20
memory mapped I/O base 0xd9840000, size 0x20000
memory mapped I/O base 0xd9860000, size 0x20000
I/O base 0x0000bfc0, size 0x20
Baseboard Management Controller:
Firmware Version: 1.2
IPMI version: 2.0
DHCP: off
BMC MAC address: 00:a0:98:0d:54:72
IP address: 10.41.251.2
IP mask: 255.255.255.0
Gateway IP address: 10.41.251.1
BMC ARP interval: 10 seconds
BMC has (1) user: naroot
ASUP enabled: on
ASUP mailhost:
ASUP from:
ASUP recipients: autosupport@netapp.com
Uptime: 0 Days, 00:07:55
