Greentec Systems is proud to offer the IBM Power System S822 (8284-22A) server uses a recent POWER8 processor technology that is designed to deliver unprecedented performance, scalability, reliability, and manageability for demanding commercial workloads. Offered in both a refurbished used IBM S822 8284-22A and New IBM server.

This server brings together business transaction processing with infrastructure for social and mobile solutions in UNIX and Linux operating environments. Based on POWER8 processors, this server delivers two times the throughput of Intel based offerings for comparable workloads and provides superior economics for scale-out deployments.

The Power S822 server for existing customers is designed to put data to work. With a strong commitment to optimizing AIX, and IBM i workloads, this system delivers better performance than the prior generation of systems and offers unmatched price and performance value for integrated Linux applications.
The one or two socket servers provide the ideal foundation for private and public cloud infrastructure. The Power S822 is available in 4-core, 6-core, 8-core, 10-core, 12-core, 16-core and 20-core configurations and supports new I/O capabilities, including Coherent Accelerator Processor Interface (CAPI) accelerators, higher internal disk and solid-state drive (SSD) capacities, and hot-plug PCIe Gen3 slots. The highly secure architecture provides a stable database and middleware platform for efficient deployment of business processing applications.

[themify_button text=”#013d1a” color=”#3e6b00″ bgcolor=”green” size=”xlarge” link=”https://www.redbooks.ibm.com/redpapers/pdfs/redp5102.pdf”]Download the S822 server technical sheet from IBM[/themify_button]

IBM S822 server Features

• Ideal for consolidation of multiple applications and infrastructure workloads in a virtualized environment, bringing together business transaction processing with infrastructure for social and mobile solutions
• Consolidation of UNIX and x86 Linux workloads
• Gain faster insights with the IBM® POWER8™ processor and smart acceleration enabled by Coherent Accelerator Processor Interface (CAPI) technologies
• Reduce energy consumption utilizing advanced energy control

New innovation brings faster insight to the point of impact for today’s data hungry applications

Built with innovation that puts data to work, IBM Power Systems™ deliver the foundation for organizations to bring insight to the point of impact 2x faster. These first generation systems push the physical and virtual boundaries of data center technology with innovation designed to drive faster and more efficient data-centric applications required for today’s smarter enterprise.

With new innovations, Power Systems provide the ability to:

• Gain faster insights with the POWER8 processor and smart acceleration enabled by CAPI technologies such as accelerators for key workloads
• Achieve lower latency and smaller footprint with CAPI Flash
• Move data in and out of systems more quickly with twice the memory and I/O expansion
• Achieve greater speed and efficiency for database, transactional and other highly multi-threaded applications with transactional memory supported by 50 percent more cores and 2x the number of simultaneous threads per core

PCIe Gen3 I/O expansion drawer

The 19-inch 4 EIA (4U) PCIe Gen3 I/O expansion drawer (#EMX0) and up to two PCIe Fan Out Modules (#EMXF) provide up to twelve PCIe I/O full-length, full-height slots. One Fan Out Module provides six PCIe slots labeled C1 through C6. C1 and C4 are x16 slots and C2, C3, C5, and C6 are x8 slots. PCIe Gen1, Gen2, and Gen3 full-high adapter cards are supported. A blind swap cassette (BSC) is used to house the full-high adapters that go into these slots. The BSC is the same BSC as used with the previous generation server’s 12X attached I/O drawers (#5802, #5803, #5877, #5873). The drawer is shipped with a full set of BSC, even if the BSC is empty. Concurrent repair and add/removal ofPCIe adapter cards is done by HMC guided menus or by operating system support utilities. A PCIe3 Optical Cable Adapter for PCIe3 Expansion Drawer (#EJ05) and 3.0 m (#ECC7) or 10.0 m (#ECC8) CXP 16X Active Optical cables (AOC) connect the system node to a PCIe Fan Out module in the I/O expansion drawer. One feature #ECC7 or one #ECC8 ships two AOC cables. Each PCIe Gen3 I/O expansion drawer has two power supplies. A maximum of a half PCIe Gen3 I/O expansion drawer (one Fan Out module) is supported on the one socket Power S822 system. A maximum of one PCIe Gen3 I/O expansion drawer (two Fan Out modules) is supported on the two sockets Power S822 system. Figure 1-3 shows a PCIe Gen3 I/O expansion drawer.

EXP24S SFF Gen2-bay drawer

If you need more disks than are available with the internal disk bays, you can attach additional external disk subsystems such as the EXP24S SAS HDD/SSD expansion drawer (#5887). The EXP24S SFF Gen2-bay drawer is an expansion drawer supporting up to twenty-four 2.5-inch hot-swap SFF SAS HDDs on IBM POWER6®, IBM POWER6+™, IBM POWER7®, IBM POWER7+™, or POWER8 servers in 2U of 19-inch rack space. The EXP24S bays are controlled by SAS adapters or controllers that are attached to the I/O drawer by SAS X or Y cables. The EXP24S drawer is attached to SAS ports on either a PCIe SAS adapter in the server or to the SAS ports on the rear of the server. Two SAS ports on the rear of the server are enabled with the expanded-function storage backplane with dual IOA support (#EJ0U). A maximum of 14 EXP24S drawers are supported on the Power S822. The SFF bays of the EXP24S differ from the SFF bays of the POWER8 system units. The EXP24S uses Gen2 or SFF-2 SAS drives that physically do not fit in the SFF-3 bays of the POWER8 system unit. The EXP24S includes redundant AC power supplies and two power cords.
