IBM Lenovo Flex System x440 Compute Node 7917 Xeon E5-4620 2.2 GHz 7917D4U
REQUEST A PRICE QUOTE:
Greentec Systems is proud to offer the Lenovo IBM Flex System x440 Compute Node. An Intel-processor based server optimized for high-end virtualization, mainstream database deployments, and memory-intensive high performance environments.
Main Features
- Server
- blade
- 4-way
- 1 x Xeon E5-4620 / 2.2 GHz
- RAM 8 GB
- SAS
- hot-swap 2.5″
- G200eR2
- GigE
- 10 GigE
- no OS
[themify_button bgcolor=”green” size=”large” link=”https://www.lenovo.com/images/products/system-x/pdfs/datasheets/x440_ds.pdf”]Download the IBM Datasheet[/themify_button]
Versatile
- Designed to run a variety of workloads, including high-end virtualization and mainstream databases
- A great choice of processors, memory, internal storage, and I/O options, allowing for flexible configurations
- Supported in the IBM Flex System Enterprise Chassis
Easy to use
- Two hot-swapped storage bays that support SAS/SATA drives, enabling drives to be removed easily for replacement or upgrade
- An optional embedded hypervisor that helps enable “instant virtualization”
- Light path diagnostics and Predictive Failure Analysis to help enable quick serviceability and maintenance
- Real-time management of the system day one out of the box via the Flex System Management, with a preconfigured and preinstalled interface
Performance optimized
- Next-generation Intel Xeon™ E5-4600 family processors, up to four processors, 130 W each
- Memory capacity with 48 DDR3 DIMM slots supporting up to 1,536 GB using 32 GB LRDIMMs
- Support for running 2DPC at 1600 MHz
- High-speed I/O that supports up to a total of eight physical 10 Gb ports or up to 64 ports of Virtual Fabric
Power and cooling
- Low-power processors and low-power memory DIMMs
- Energy-efficient 1.35 V DIMM support
- Active Energy Manager to help monitor and cap power consumption
- Advanced management that supports limiting power consumption and real-time power and thermal management
- Innovative and robust design to help keep the compute node performing under demanding conditions
IBM Lenovo Flex System compute nodes
Compute nodes typically contain the number and type of microprocessors, memory modules, and hard disk drives that are needed to support a specific workload environment. These nodes use integrated network ports or optional network adapters to connect to external devices through the switches or modules that are installed in the chassis.
Note: The network adapters and ports in the nodes must be compatible with the network switches or modules in the chassis.
These compute nodes come with Intel Xeon microprocessors and provide the function, reliability, and performance in a small form factor design. They support a variety of Microsoft™ Windows™ , Linux™ , and VMware operating systems and are ideally suited for high-performance and virtualized environments such as memory-intensive computing, collaboration, general and mission-critical processing, and enterprise application workloads. All models come with an integrated management module (IMM2) that connects to the Chassis Management Module to provide the integrated systems-management functions for the node.
Flex System x440 Compute Node
The IBM Flex System x440 Compute Node is a high-density server optimized for high-end virtualization, mainstream database deployments, and memory-intensive high performance environments.
The Flex System x440 Compute Node provides support for optional devices, such as the following devices:
- Up to four multicore microprocessors
- Up to 48 low profile dual inline memory modules (DIMMs)
- Up to two hot-swap storage drives
- Up to four I/O expansion adapters (model dependent)
- Up to two internal bootable USB flash keys
The Flex System x440 Compute Node is supported in the IBM Flex System Enterprise Chassis only.
The IBM Flex System x440 Compute Node supports memory mirroring. Chipkill is supported in any mode when x4-based DIMM memory is used. Chipkill memory correction for up to four bits per DIMM helps to keep your server up and running.
Standard IBM Flex System x440 Compute Node configuration
Model information
Intel
Xeon CPU CPU Memory/ HDD
Model name Cores speed GT/s power type interface
7917-F4x E5-4650 8 2.7 GHz 8.0 130w 1x8 GB H/S SFF
Cache: 20 MB 1600 MHz
7917-F2x E5-4650 8 2.7 GHz 8.0 130w 1x8 GB H/S SFF
Cache: 20 MB 1600 MHz
7917-D4x E5-4620 8 2.2 GHz 7.2 95w 1x8 GB H/S SFF
Cache: 16 MB 1333 MHz
7917-D2x E5-4620 8 2.2 GHz 7.2 95w 1x8 GB H/S SFF
Cache: 16 MB 1333 MHz
7917-C4x E5-4610 6 2.4 GHz 7.2 95w 1x8 GB H/S SFF
Cache: 15 MB 1333 MHz
7917-C2x E5-4610 6 2.4 GHz 7.2 95w 1x8 GB H/S SFF
Cache: 15 MB 1333 MHz
7917-B4x E5-4607 6 2.2 GHz 6.4 95w 1x8 GB H/S SFF
Cache: 12 MB 1333 MHz
7917-B2x E5-4607 6 2.2 GHz 6.4 95w 1x8 GB H/S SFF
Cache: 12 MB 1333 MHz
7917-A4x E5-4603 4 2.0 GHz 6.4 95w 1x8 GB H/S SFF
Cache: 10 MB 1333 MHz
7917-A2x E5-4603 4 2.0 GHz 6.4 95w 1x8 GB H/S SFF
Cache: 10 MB 1333 MHz
EMEA x = G
Additional features
- The IBM Flex System x440 Compute Node system board contains 48 DIMM connectors.
- Each DIMM connector supports 4 GB, 8 GB, 16 GB, or 32 GB low-profile (LP) double date rate (DDR3) DRAM.
- Chipkill is supported in x4 DIMM memory configurations only.
- Support is provided for up to two hot-swap, Small Form Factor (SFF) Serial Attached SCSI (SAS), Serial ATA (SATA), or Solid State (SSD) storage drives.
- Dual 10-Gigabit Ethernet connections are provided on select models.
IBM Flex System x440 Compute Node servers are designed for high throughput from processor to memory, and to bus I/O.
These features, combined with SMP capability and blade-thin density, make it an excellent choice for space- and power-constrained environments used for:
- Database
- Virtualization
- General enterprise applications such as ERP and SCM
- Simulations
High-availability and serviceability features
- Hot-swap capabilityHot-swap compute nodes enable easy access to each node server.
- Management moduleThe management module interfaces with each node server for single systems management control.
- Dynamic System Analysis (DSA)IBM Dynamic System Analysis (DSA) collects and analyzes system information to aid in diagnosing compute node problems. DSA collects the following information about the compute node:
- Drive health information
- Event logs for ServeRAID controllers and service processors
- Hardware inventory, including PCI and USB information
- Installed applications and hot fixes
- Kernel modules
- Light path diagnostics status
- Network interfaces and settings
- Performance data and details about processes that are running
- RAID and controller configuration
- Integrated management module 2 status and configuration
- System configuration
- Vital product data and firmware information
DSA creates a DSA log, which is a chronologically ordered merge of the system-event log (as the IPMI event log), the IMM event log (as the ASM event log), and the operating-system event logs. You can send the DSA log as a file to a support representative or view the information as a text file or HTML file.
- Flexible network supportThe compute node provides flexible network capabilities:
- The integrated Emulex BE3 dual-port Gigabit Ethernet (select models) controller supports connections to a 1 Gbps or 10 Gbps network through an Ethernet-compatible switch module in the chassis. The controller also supports Wake on LAN technology.
- The compute node has connectors on the system board for optional expansion adapters for adding network communication capabilities to the compute node. Depending on the model, you can install up to four I/O expansion adapters for network support. This provides the flexibility to install expansion adapters that support a variety of network communication technologies.
- Hard disk drive supportThe compute node supports up to two hot-swap hard disk drives. You can implement RAID 0 or RAID 1 for the drives.
- IBM ServerGuide Setup and Installation CDThe ServerGuide Setup and Installation CD, which you can download from the web, provides programs to help you set up the compute node and install a Windows operating system. The ServerGuide program detects installed optional hardware devices and provides the correct configuration programs and device drivers.
- Integrated management module 2 (IMM2)The integrated management module 2 (IMM2) combines systems-management function, video controller, the remote presence, and blue-screen capture features in a single chip. The IMM2 provides advanced systems-management control, monitoring, and alerting function. If an environmental condition exceeds a threshold or if a system component fails, the IMM2 lights LEDs to help you diagnose the problem, records the error in the IMM event log, and alerts you to the problem.Optionally, the IMM2 also provides a virtual presence capability for remote systems management capabilities. The IMM2 provides remote systems management through industry-standard interfaces:
- Common Information Model (CIM)
- Intelligent Platform Management Interface (IPMI) version 2.0
- Simple Network Management Protocol (SNMP) version 3.0
- Web browser
- Large system-memory capacityThe compute node supports up to 1,536 GB of system memory. The IBM Flex System x440 Compute Node provides support for up to 48 industry-standard registered or LRDIMM ECC DDR3 on low-profile (LP) DIMMs on the system board.
- Light path diagnosticsLight path diagnostics provides light-emitting diodes (LEDs) to help diagnose problems.
- Microprocessor technologyThe compute node supports up to four multicore Intel Xeon microprocessors.
- Peripheral Component Interconnect Express® (PCIe)PCIe is a computer expansion bus that is used for chip-to-chip interconnect and expansion adapter interconnect. You can add optional I/O and storage devices.
- Power throttlingBy enforcing a configurable power policy known as power-domain oversubscription, the IBM Flex System chassis will allow for a larger overall chassis power budget depending on the number of power supplies installed. When a fault occurs in one or more power supplies, the power supplies can run oversubscribed for a short period of time. During this time period the compute nodes will throttle to safe power level in order to allow all components in the chassis to stay operational and survive the power supply failure. This policy is enforced by the Chassis Management Module in cooperation with every installed compute node in the IBM Flex System chassis. The policy is in effect when initial power is applied to the IBM Flex System chassis or when an administrator changes the policy.The following settings for this policy are available:
- Basic power management
- Power module redundancy (N+N or N+1)
- Power module redundancy with compute node throttling allowed (N+N or N+1)
An administrator can configure the policy and monitor the overall chassis power environment by using the Chassis Management Module user interface.
- Systems-management supportThe compute node supports the IBM Flex System Chassis Management Module (CMM) and IBM Flex System Manager management software.
- CMM is a hot-swap module that provides system-management functions for all components in an IBM Flex System chassis. It controls a serial port for remote connection and a 10/100 Mbps Ethernet remote-management connection.
- IBM Flex System Manager management software is a platform-management foundation that streamlines the way you manage physical and virtual systems in a heterogeneous environment. By using industry standards, IBM Flex System Manager management software supports multiple operating systems and virtualization technologies.
Flex System networking portfolio
Networking in datacenters today is undergoing a transition from a discrete traditional model to a more flexible, optimized model or the “smarter” model. Clients are looking to support more workloads with decreasing or flat IT budget. The network architecture on the Flex System platform has been designed to address the key challenges clients are facing today in their datacenters. The key attributes of the network architecture on this platform are:
- Integrated
- Efficient integrated management as part of the management appliance
- Move from physical network management to logical network management in a virtualized environment
- Automated
- Seamless provisioning, management, and deployment of both physical and virtual network parameters using tools like Virtual Fabric Manager, IBM SoftSwitch (5000v), and VMready®
- Optimized
- Creation of a flat logical network so there are fewer elements to manage
- Reduced cost and complexity by leveraging IBM Virtual Fabric and I/O convergence
- Reduced risk and cost by leveraging scalable switches that can provide both port and bandwidth flexibility
One of the key attributes of the products on this platform is scalability. When modules are marked “Scalable” this means that clients can buy the base product with a certain number of ports and when they need to scale up for more ports, they can just buy the license to enable the extra ports without having to provision any new hardware.
The Flex System networking portfolio includes:
- IBM Flex System EN2092 1Gb Ethernet Scalable SwitchThis 1 Gb scalable switch is for clients looking to use the value of Flex System without moving to a 10 Gb environment. Key features of this switch module are:
- The switch supports up to two logical partitions per physical switch.
- It is a 52-port switch with 28 internal 1 Gb ports, 20 external 1 Gb ports, and 4 external 10 Gb ports.
- The base switch provides 14 internal 1 Gb ports and 10 external 1 Gb RJ45 ports.
- Upgrade 1 offers 14 additional internal 1 Gb ports and 10 additional external 1 Gb RJ45 ports.
- Upgrade 2 enables the four 10 Gb uplink ports.
- Upgrade 1 can be applied to the base switch or to Upgrade 2.
- 10 Gb SFP+ ports can function at 1 Gb or 10 Gb.
- The switch provides support for full L2/L3 Ethernet functionality.
The IBM Flex System EN2092 1Gb Ethernet Scalable Switch offers 14 internal 1 Gb ports to each compute node and ten external 1 Gb ports as uplinks. The external ports are RJ45.
- IBM Flex System EN2092 1 Gb Ethernet Scalable Switch (Upgrade 1)Clients who require either more than two 1 Gb ports per server or more bandwidth can enable additional ports by using this switch upgrade. This option enables another 14 internal 1 Gb ports to each compute node and 10 additional external 1 Gb uplinks.
- IBM Flex System EN2092 1Gb Ethernet Scalable Switch (10 Gb Uplinks) (Upgrade 2)This option enables the four 10 Gb uplinks on this switch module for clients who require higher performance and bandwidth to connect to 10 Gb Top-of-Rack (ToR) switch modules. Clients need to purchase at least the base switch before they can enable these uplinks. These uplinks can be enabled on either partition of the switch.
- IBM Flex System Fabric EN4093 10Gb Scalable SwitchThis 10 Gb scalable switch offers uncompromised scalability, throughput, and performance. This switch can help clients migrate to 10 Gb infrastructure and offers virtualization features like Virtual Fabric and VMready . Clients should consider this switch if they:
- Are building a 10 Gb Ethernet infrastructure or migrating from 1 Gb to 10 Gb (mixed environment)
- Are deploying virtualization
- Want investment protection to upgrade to more ports and bandwidth (40 Gb)
Some of the key features of this switch are:
- This is a triple-density switch with the ability to scale based on your needs.
- It offers a total 64 ports with 42 internal 10 Gb ports and 22 external 10 Gb ports.
- The base switch provides 14 internal 10 Gb ports and 10 external SFP+ 10 Gb ports.
- Upgrade 1 provides 14 additional internal 10 Gb ports and enables two 40 Gb QSFP ports that can be used as four 10 Gb ports.
- Upgrade 2 offers 14 additional internal 10 Gb ports and enables 4 external SFP+ 10 Gb ports.
- Upgrade 1 is required to apply Upgrade 2.
- 10 Gb SFP+ ports can function at 1 Gb or 10 Gb.
- 40 Gb QSFP ports can function at 10 Gb or 40 Gb.
- The switch provides full Layer 2/3 Ethernet function.
- The switch offers Virtual Fabric support and management.
This base switch model will enable 14 internal 10 Gb ports, one to each compute node, and 10 external 10 Gb ports to connect to a ToR switch module. All external 10 Gb ports are SFP+ based connections.
- IBM Flex System Fabric EN4093 10Gb Scalable Switch (Upgrade 1)This switch upgrade can be applied on the base switch when you require support for four ports of 10 Gb on the server or if you just want more uplink bandwidth on the base switch. The upgrade will enable 14 additional internal 10 Gb ports, one to each compute node, and two 40 Gb uplinks. These 40 Gb uplinks are QSFP connectors but can be converted to four 10 Gb uplinks using fan out cable. This upgrade can be applied if you already have the base switch model.
- IBM Flex System Fabric EN4093 10Gb Scalable Switch (Upgrade 2)This switch upgrade can be applied on top of Upgrade 1 when you want to support six ports of 10 Gb on the server or if you just want more uplink bandwidth on the base switch. The upgrade will enable 14 additional internal 10 Gb ports, one to each compute node, and four 10 Gb uplinks. These uplinks are SFP+ ports.
- IBM Flex System EN4091 10Gb Ethernet Pass-thruThis module offers easy connectivity of the Flex System Chassis to an external network infrastructure. This is an unmanaged device enabling direct connectivity of a compute node in the chassis to an external Top-of-Rack switch. This module can function at both 1 Gb and 10 Gb speeds. It has 14 internal links and 14 external SFP+ uplinks.
- IBM Flex System EN2024 4-port 1Gb Ethernet AdapterThis four-port 1 Gb adapter can provide 1 Gb connectivity to clients. When it is combined with the IBM Flex System EN2092 1Gb Ethernet Scalable Switch, clients can leverage an end-to-end 1 Gb solution on Flex System Chassis. This adapter is based on Broadcom 5718 ASIC and supports a PCIe Gen2 x4 interface with MSI/MSI-X. It also supports I/O virtualization features like VMware NetQueue and Microsoft VMQ technologies.
- IBM Flex System CN4054 10Gb Virtual Fabric Adapter and IBM Flex System CN4054 Virtual Fabric Adapter (software upgrade)This is a four-port 10 Gb adapter that can scale up to 16 virtual ports and support multiple protocols like Ethernet, iSCSI, and FCoE. This adapter uses the third generation of Emulex ASIC (BE3) that supports hardware offload and acceleration for network and storage protocols. By using a common infrastructure for Ethernet and storage networks, datacenters can reduce capital expenses (CAPEX) and operating expenses (OPEX). Key features of this adapter are:
- Each 10 Gb physical port can support up to four virtual ports (vNIC).
- Each vNIC appears as an individual adapter to the operating system.
- Each vNIC allocates bandwidth at increments of 100 Mb.
- Clients can run advanced protocols like HW iSCSI or FCoE on one of the vNICs per physical port via the software upgrade key.
- The adapter can connect at 1 Gb or 10 Gb speed.
This adapter will support the following modes of operations:
- Physical Mode (pNIC): In this mode the adapter will present four ports of 10 Gb and clients can upgrade to run either FCoE or HW iSCSI to connect to a storage target.
- IBM Virtual Fabric Mode: In this mode each of the physical 10 Gb ports can present up to four virtual ports to the operating system. Therefore on this card, users can get up to 16 virtual ports. Clients can set the bandwidth of each of these virtual ports at increments of 100 Mb. Additionally they can apply the software upgrade to run storage protocols (HW iSCSI or FCoE) on four of the 16 virtual ports. This mode works with the IBM 10Gb Virtual Fabric Switch to provide end-to-end I/O virtualization. This adapter ships by default in this mode.
- Switch Independent Mode: This functions like the IBM Virtual Fabric Mode except no setting or changes are required on the switch side. The adapter presents four virtual ports per physical port but on the switch side it is still a single 10 Gb port. This mode will enable clients to leverage the IBM Virtual Fabric capability with the 10Gb Pass-thru module also.
Key benefits of this adapter are:
- Ability to maximize I/O consolidation with high-performance 10 Gb ports
- One adapter to run multiple protocols
- Simplified setup and management options like CLI, Switch Interface, or Virtual Fabric Manager
- IBM Flex System EN4132 2-port 10Gb Ethernet AdapterThis two-port 10 Gb adapter is based on Mellanox Connect X3 ASIC. This is a PCIe Gen 3 adapter that supports next-generation technology like RDMA and RoCE. Other key features of this adapter are:
- Application acceleration
- Low latency for specialized apps
This adapter will work with the 10 Gb Flex System Fabric Switch and 10 Gb Pass-thru modules.
Fibre Channel Switch and Adapters
- IBM Flex System FC3171 8Gb SAN Switch and IBM Flex System FC3171 8Gb SAN Pass-thruThese SAN modules enable 8 Gb connectivity to storage from the Flex System Chassis. These SAN modules offer enhanced Fibre Channel functions like Port Aggregation, Auto-StreamGuard, Enhanced N_Port ID Virtualization (NPIV), and Automatic Failover.Both of these modules run at high-performance 8 Gb speed. Two part numbers are offered to meet clients’ requirements whether they need full switching function in the chassis or just a simple pass-thru solution.
- IBM Flex System FC5022 24-port 16Gb ESB SAN Scalable Switch, IBM Flex System FC5022 16Gb SAN Scalable Switch, and IBM Flex System FC5022 2-port 16Gb FC AdapterThese SAN switch modules and HBA deliver an embedded option for IBM Flex System users deploying storage area networks in their enterprise. They offer end-to-end 16 Gb and 8 Gb connectivity. These scalable switches enable Dynamic Ports on Demand (DPOD) and grow with the needs of the clients. The N-Port Virtualization mode streamlines the infrastructure by reducing the number of domains to manage while enabling the ability to add or move servers without impact to the SAN. Management is simplified via an integrated management appliance, or clients using end-to-end Brocade SAN can leverage the Brocade management tools.Key features of this switch:
- Superior scalability to allow greater intrachassis connectivity
- Extension, encryption, and compression capable
- Diagnostic Port (D-Port) for superior validation and serviceability of network
- Total of 48 ports wired with 28 ports internal and 20 external
- Based on Brocade’s seventh-generation Fibre Channel Switch ASIC
Two versions of this switch are available:
- IBM Flex System FC5022 16Gb SAN Scalable SwitchThis switch comes with 12 Dynamic Ports on Demand (DPOD) licenses that can be applied to either internal or external links on this switch. Clients who do not fully populate the chassis can leverage this switch without having to pay for ports they are not using.
- IBM Flex System FC5022 24-port 16Gb Enterprise SAN Scalable SwitchThis switch comes with 24 DPOD licenses that can be applied to either internal or external links on this switch. This switch will also include these enhanced software licenses installed:
- ISL Trunking (up to 128Gb ISL Trucks)
- Adaptive Networking
- Advanced Performance Monitoring
- Fabric Watch
- Extended Fabrics
- Server Application Optimization
To complement the 16Gb switches, we will offer a two-port 16 Gb adapter based on Brocade architecture to offer end-to-end 16 Gb connectivity to a SAN. This adapter can autonegotiate and work at 8 Gb speed also. It offers enhanced features like storage Target Rate Limiting (TRL), VM aware Quality of Service (QoS) and 1M+ IOPS performance.
Clients can manage these devices via the integrated Flex System Manager or for advanced monitoring they can use the Brocade Network Advisor.
In summary, these SAN switches and adapter offer these key values:
- First 16 Gbps embedded switch with up to 640 Gb bandwidth
- Investment protection; growth in ports and bandwidth
- Superior scalability to allow greater intrachassis connectivity
- ISL Trunks up to 128 Gb for superior performance, resiliency, and management
- Extension, encryption, and compression capable
- Diagnostic Port (D-Port) for superior serviceability
- VM aware Quality of Service from adapter through entire network
- IBM Flex System FC3172 2-port 8Gb FC AdapterThe QLogic 8Gb Fibre Channel adapter enables high-speed access for Flex System compute nodes to connect to a Fibre Channel storage area network (SAN). This adapter is based on the proven QLogic 2532 8 Gb ASIC design and works with any of the 8 Gb or 16 Gb Flex System Fibre Channel switch modules. When compared to the previous-generation 4 Gb adapters, the new-generation 8 Gb adapters double the throughput speeds for Fibre Channel traffic. As a result, you can manage increased amounts of data and possibly benefit from a reduced hardware expense.
- IBM Flex System FC3052 2-port 8Gb FC AdapterThe Emulex 2-port 8Gb Fibre Channel adapter enables high-speed access for Flex System compute nodes to an external storage area network (SAN). This adapter is based on the proven Emulex Fibre Channel stack and works with any of the 8 Gb or 16 Gb Flex System Fibre Channel switch modules. When compared to the previous-generation 4 Gb adapters, the new-generation 8 Gb adapters double the throughput speeds for Fibre Channel traffic. As a result, you can manage increased amounts of data and possibly benefit from a reduced hardware expense.
InfiniBand switch and adapters
- IBM Flex System IB6131 InfiniBand Switch, IBM Flex System IB6132 2-port QDR InfiniBand Adapter, and IBM Flex System IB6132 2-port FDR InfiniBand Adapter
InfiniBand is a high-speed server-interconnect technology that is ideally suited as the interconnect technology for access layer and storage components specifically for application and back-end IPC applications, for connectivity between application and back-end layers, and from back-end to storage layers. Through use of host channel adapters (HCAs) and switches, InfiniBand technology is used to connect servers with remote storage and networking devices, and other servers. It can also be used inside servers for interprocessor communication (IPC) in parallel clusters.
The IBM Flex System IB6131 InfiniBand Switch is an upgradable device that can scale with your needs. The base switch enables 14 internal QDR links to each server and 18 QSFP uplink ports for interswitch links or to connect to external servers. Clients can upgrade to FDR speed (56 Gb) via the Feature On Demand (FOD) process.
The InfiniBand QDR and FDR switches based on Mellanox technology are unmanaged switches. A subnet manager is required to establish an InfiniBand fabric. This module supports switch-embedded subnet managers and host-based subnet managers.
IBM Flex System suits multiple delivery models, from highly customizable hardware platforms to a fully integrated and optimized system.
- IBM Flex System hardware ‘building blocks’ made up of individual components that can be mixed and matched, and are fully customizable with optional management
- IBM Flex System solutions made up of a chassis with an integrated management appliance, IBM networking, and storage standard
- IBM Flex System optimized offerings made up of preconfigured, highly customized systems – focused on selected workloads or single-purpose applications such as PureFlex™ or Cloudburst
The following are newly announced features on the specified models of the IBM xSeries® 7917 machine type:
Description MT Model Feature
7917-AC1 7917 AC1
7917-MC1 7917 MC1
IBM 300GB 10K 6Gbps SAS 2.5" SFF Slim-HS SED 7917 AC1 5413
MC1
IBM 200GB SATA 1.8" MLC SSD 7917 AC1 5420
MC1
IBM 50GB SATA 1.8" MLC SSD 7917 AC1 5428
MC1
Integrated Solid State Mirroring 7917 AC1 7859
MC1
Integrated Solid State Striping 7917 AC1 7860
MC1
Preload by Hardware Feature Specify 7917 AC1 9220
MC1
IBM Flex System EN2024 4-port 1Gb Ethernet Adapter 7917 AC1 A10Y
MC1
IBM 900GB 10K 6Gbps SAS 2.5" SFF HS HDD 7917 AC1 A282
MC1
IBM 300GB 15K 6Gbps SAS 2.5" SFF HS HDD 7917 AC1 A283
MC1
4GB (1x4GB, 1Rx4, 1.5V) PC3-12800 CL11 ECC DDR3
1600MHz LP RDIMM 7917 AC1 A28Z
MC1
32GB (1x32GB, 4Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP LRDIMM 7917 AC1 A291
MC1
IBM Blank USB Memory Key for VMWare ESXi Downloads 7917 AC1 A2G0
MC1
Primary Array - RAID 0 7917 AC1 A2K6
MC1
Primary Array - RAID 1 7917 AC1 A2K7
MC1
Primary Array - RAID 5 7917 AC1 A2K9
MC1
Primary Array - RAID 6 7917 AC1 A2KA
MC1
Primary Array - RAID 10 7917 AC1 A2KB
MC1
Secondary Array - RAID 0 7917 AC1 A2KF
MC1
Secondary Array - RAID 1 7917 AC1 A2KG
MC1
Secondary Array - RAID 5 7917 AC1 A2KJ
MC1
Secondary Array - RAID 6 7917 AC1 A2KK
MC1
Secondary Array - RAID 10 7917 AC1 A2KL
MC1
IBM Virtual Fabric Advanced Software Upgrade (LOM) 7917 AC1 A2TD
MC1
16GB (1x16GB, 2Rx4, 1.5V) PC3-12800 CL11 ECC DDR3
1600MHz LP RDIMM 7917 AC1 A2U5
MC1
IBM USB Memory Key for VMWare ESXi 5.0 7917 AC1 A2VC
MC1
IBM 146GB 15K 6Gbps SAS 2.5" SFF G2HS HDD 7917 AC1 A2XB
MC1
IBM 300GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 7917 AC1 A2XC
MC1
IBM 600GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 7917 AC1 A2XD
MC1
IBM 500GB 7.2K 6Gbps NL SAS 2.5" SFF G2HS HDD 7917 AC1 A2XE
MC1
ServeRAID M5115 SAS/SATA Controller for IBM Flex
System 7917 AC1 A2XW
MC1
ServeRAID M5100 Series RAID 6 Upgrade for IBM Flex
System 7917 AC1 A2Y1
MC1
ServeRAID M5100 Series Performance Upgrade for IBM
Flex System 7917 AC1 A2Y2
MC1
ServeRAID M5100 Series SSD Caching Enabler for IBM
Flex System 7917 AC1 A36G
MC1
Primary Array 2 HDDs 7917 AC1 7008
MC1
Primary Array 3 HDDs 7917 AC1 7009
MC1
Primary Array 4 HDDs 7917 AC1 7010
MC1
Primary Array 5 HDDs 7917 AC1 7011
MC1
Primary Array 6 HDDs 7917 AC1 7012
MC1
Primary Array 7 HDDs 7917 AC1 7013
MC1
Primary Array 8 HDDs 7917 AC1 7014
MC1
Secondary Array 2 HDDs 7917 AC1 7015
MC1
Secondary Array 3 HDDs 7917 AC1 7016
MC1
Secondary Array 4 HDDs 7917 AC1 7017
MC1
Secondary Array 5 HDDs 7917 AC1 7057
MC1
Secondary Array 6 HDDs 7917 AC1 7058
MC1
IBM Flex System 1.8" SSD Filler 7917 AC1 A3EP
MC1
ServeRAID M5100 Series Left Side Air Baffle for 7917 AC1 A3F6
IBM Flex System x440 MC1
The following are features already announced for the 7917 machine type:
Description MT Model Feature
7917-AC1 7917 AC1
7917-MC1 7917 MC1
Integrated SATA Mirroring - 2 identical HDDs
required 7917 AC1 0030
MC1
Integrated SATA Striping - 2 identical HDDs
required 7917 AC1 0031
MC1
UID Asset Tag Label 7917 AC1 0747
MC1
EMEA Long Leadtime Configurations 7917 AC1 1763
MC1
Hungary CHW plant 9SH 7917 AC1 1764
MC1
Guad CHW plant 9KQ 7917 AC1 1765
MC1
ISTC CHW 9K2 7917 AC1 1766
MC1
RTP CHW 9NR 7917 AC1 1767
MC1
Offload Manufacturing to Guadalajara HVEC 7917 AC1 1768
MC1
Offload Manufacturing to RTP HVEC 7917 AC1 1769
MC1
Offload Manufacturing to ISTC 7917 AC1 1770
MC1
Routing for AP Foxconn 7917 AC1 1771
MC1
Capacity Scheduling Service 7917 AC1 1772
MC1
Custom SLA Scheduling Service 7917 AC1 1796
MC1
Custom Asset Tagging - Standard 7917 AC1 2200
MC1
Custom Asset Tagging - Enhanced 7917 AC1 2201
MC1
Custom Image Load - Server 7917 AC1 2204
MC1
Custom Media Shipgroup 7917 AC1 2206
MC1
Request for Global Trade Number (UPC or EAN) 7917 AC1 2207
MC1
Custom Software/Firmware Setting - Standard 7917 AC1 2208
MC1
Custom Software/Firmware Setting - Enhanced 7917 AC1 2209
MC1
Custom RAID Configuration 7917 AC1 2212
MC1
Custom Labeling 7917 AC1 2220
MC1
Custom Palletization 7917 AC1 2221
MC1
Request for a new Vendor Logo Hardware 7917 AC1 2247
MC1
Select Storage devices - no IBM-configured RAID
required 7917 AC1 5977
MC1
Select Storage devices - IBM-configured RAID 7917 AC1 5978
MC1
SOFS Solution Code MFG Instruction 7917 AC1 6124
MC1
SAP-BWA Solution Code MFG Instruction 7917 AC1 6125
MC1
InfoSphere-BWA Solution Code MFG Instruction 7917 AC1 6126
MC1
GMAS Solution Code MFG Instruction 7917 AC1 6127
MC1
IBW-SSD Solution Code MFG Instruction 7917 AC1 6128
MC1
Cloudburst Solution Code MFG Instruction 7917 AC1 6129
MC1
SoNAS Solution Code MFG Instruction 7917 AC1 6130
MC1
2.5" Gen2 HS HDD Filler 7917 AC1 6421
MC1
China Warranty 7917 AC1 7599
MC1
Customer Solution Center Services 7917 AC1 7831
MC1
e1350 Special Bid Solution Component 7917 AC1 7929
MC1
No HDD Selected 7917 AC1 8026
MC1
No Processor Selected 7917 AC1 8028
MC1
No Memory Selected 7917 AC1 8029
MC1
Consolidate Shipment 7917 AC1 8031
MC1
e1350 Solution Component 7917 AC1 8034
MC1
Compute Node 7917 AC1 8036
MC1
Management Node 7917 AC1 8037
MC1
Storage Node 7917 AC1 8038
MC1
Integrated SAS Mirroring - 2 identical HDDs
required 7917 AC1 8039
MC1
Integrated SAS Striping - 2 identical HDDs
required 7917 AC1 8040
MC1
TAA Compliant Order 7917 AC1 8067
MC1
General Racking Solution 7917 AC1 8072
MC1
Integrate BladeCenter® in Manufacturing 7917 AC1 8077
MC1
No 2.5" SAS HDD Selected 7917 AC1 8081
MC1
No Publications Selected 7917 AC1 8086
MC1
8GB (1x8GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP RDIMM 7917 AC1 8923
MC1
4GB (1x4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP RDIMM 7917 AC1 8941
MC1
4GB (1x4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP RDIMM 7917 AC1 8942
MC1
System x Cluster Upgrade 7917 AC1 A103
MC1
IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 7917 AC1 A1AV
MC1
IBM Flex System FC3172 2-port 8Gb FC Adapter 7917 AC1 A1BM
MC1
IBM Flex System FC5022 2-port 16Gb FC Adapter 7917 AC1 A1BP
MC1
IBM 250GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 7917 AC1 A1NX
MC1
IBM 500GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 7917 AC1 A1NZ
MC1
IBM 1TB 7.2K 6Gbps NL SAS 2.5" SFF HS HDD 7917 AC1 A1P3
MC1
16GB (1x16GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP RDIMM 7917 AC1 A1QT
MC1
IBM Flex System EN4132 2-port 10Gb Ethernet
Adapter 7917 AC1 A1QY
MC1
IBM Flex System IB6132 2-port FDR Infiniband
Adapter 7917 AC1 A1QZ
MC1
IBM Flex System CN4054 Virtual Fabric Adapter (SW
Upgrade) 7917 AC1 A1R0
MC1
IBM Flex System CN4054 10Gb Virtual Fabric Adapter 7917 AC1 A1R1
MC1
IBM Flex System x240 Compute Node Air Baffle 7917 AC1 A248
MC1
IBM Flex System Compute Node Fabric Connector 7917 AC1 A26R
MC1
16GB (1x16GB, 4Rx4, 1.35V) PC3L-10600 CL9 ECC DDR3
1333MHz LP LRDIMM 7917 AC1 A290
MC1
8GB (1x8GB, 2Rx4, 1.5V) PC3-12800 CL11 ECC DDR3
1600MHz LP RDIMM 7917 AC1 A292
MC1
IBM Flex System x440 Compute Node with embedded
10Gb Virtual Fabric 7917 AC1 A2BC
MC1
IBM Flex System x440 Compute Node 7917 AC1 A2BD
MC1
IBM Flex System x440 Compute Node Label 7917 AC1 A2BE
MC1
IBM Flex System x440 Compute Node Cover 7917 AC1 A2BF
MC1
IBM Flex System x440 Compute Node Front Bezel 7917 AC1 A2BG
MC1
System Documentation and Software-US English 7917 AC1 A2BJ
MC1
SAS HDD 1 x 2.5" Backplane 7917 AC1 A2BY
MC1
Intel Xeon Processor E5-4603 4C 2.0GHz 10M Cache
1066MHz 95W 7917 AC1 A2C0
MC1
Addl Intel Xeon Processor E5-4603 4C 2.0GHz 10MB
Cache 1066MHz 95W 7917 AC1 A2C1
MC1
Addl Intel Xeon Processor E5-4603 4C 2.0GHz 10MB
Cache 1066MHz 95W 7917 AC1 A2C2
MC1
Intel Xeon Processor E5-4607 6C 2.2GHz 12M Cache
1066MHz 95W 7917 AC1 A2C3
MC1
Addl Intel Xeon Processor E5-4607 6C 2.2GHz 12MB
Cache 1066MHz 95W 7917 AC1 A2C4
MC1
Addl Intel Xeon Processor E5-4607 6C 2.2GHz 12MB
Cache 1066MHz 95W 7917 AC1 A2C5
MC1
Intel Xeon Processor E5-4610 6C 2.4GHz 15M Cache
1333MHz 95W 7917 AC1 A2C6
MC1
Addl Intel Xeon Processor E5-4610 6C 2.4GHz 15MB
Cache 1333MHz 95W 7917 AC1 A2C7
MC1
Addl Intel Xeon Processor E5-4610 6C 2.4GHz 15MB
Cache 1333MHz 95W 7917 AC1 A2C8
MC1
Intel Xeon Processor E5-4617 6C 2.9GHz 15M Cache
1600MHz 130W 7917 AC1 A2C9
MC1
Addl Intel Xeon Processor E5-4617 6C 2.9GHz 15MB
Cache 1600MHz 130W 7917 AC1 A2CA
MC1
Addl Intel Xeon Processor E5-4617 6C 2.9GHz 15MB
Cache 1600MHz 130W 7917 AC1 A2CB
MC1
Intel Xeon Processor E5-4640 8C 2.4GHz 20M Cache
1600MHz 95W 7917 AC1 A2CC
MC1
Addl Intel Xeon Processor E5-4640 8C 2.4GHz 20MB
Cache 1600MHz 95W 7917 AC1 A2CD
MC1
Addl Intel Xeon Processor E5-4640 8C 2.4GHz 20MB
Cache 1600MHz 95W 7917 AC1 A2CE
MC1
Intel Xeon Processor E5-4620 8C 2.2GHz 16M Cache
1333MHz 95W 7917 AC1 A2CF
MC1
Addl Intel Xeon Processor E5-4620 8C 2.2GHz 16MB
Cache 1333MHz 95W 7917 AC1 A2CG
MC1
Addl Intel Xeon Processor E5-4620 8C 2.2GHz 16MB
Cache 1333MHz 95W 7917 AC1 A2CH
MC1
Intel Xeon Processor E5-4650 8C 2.7GHz 20M Cache
1600MHz 130W 7917 AC1 A2CJ
MC1
Addl Intel Xeon Processor E5-4650 8C 2.7GHz 20MB
Cache 1600MHz 130W 7917 AC1 A2CK
MC1
Addl Intel Xeon Processor E5-4650 8C 2.7GHz 20MB
Cache 1600MHz 130W 7917 AC1 A2CL
MC1
IBM Flex System Compute Node Full-Wide WW
packaging 7917 AC1 A2CN
MC1
RFID Tag, AG/AP: 902-928Mhz 7917 AC1 A2EV
MC1
IBM 200GB SATA 2.5" MLC HS SSD 7917 AC1 A2FN
MC1
IBM Flex System FC3052 2-port 8Gb FC Adapter 7917 AC1 A2N5
MC1
IBM Flex System x440 Compute Node Center Air
Baffle 7917 AC1 A2QQ
MC1
Intel Xeon Processor E5-4650L 8C 2.6GHz 20M Cache
1600MHz 115W 7917 AC1 A2QU
MC1
Addl Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB
Cache 1600MHz 115W 7917 AC1 A2QV
MC1
Addl Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB
Cache 1600MHz 115W 7917 AC1 A2QW
MC1
IBM 256GB SATA 2.5" MLC HS Enterprise Value SSD 7917 AC1 A2U3
MC1
IBM 128GB SATA 2.5" MLC HS Enterprise Value SSD 7917 AC1 A2U4
MC1
IBM Flex System x440 Compute Node CPU Filler 7917 AC1 A2ZM
MC1
ServeRAID M5100 Series Enablement Kit for IBM Flex
System x440 7917 AC1 A3DS
MC1
ServeRAID M5100 Series IBM Flex System Flash Kit
for x440 7917 AC1 A3DT
MC1
ServeRAID M5100 Series SSD Expansion Kit for IBM
Flex System x440 7917 AC1 A3DU
MC1
The following are features already announced for the 3331 machine type:
Description MT Model Feature Addl Intel Xeon Processor E5-4603 4C 2.0GHz 10MB Cache 1066MHz 95W 3331 HC1 A2C1 Addl Intel Xeon Processor E5-4603 4C 2.0GHz 10MB Cache 1066MHz 95W 3331 HC1 A2C2 Addl Intel Xeon Processor E5-4607 6C 2.2GHz 12MB Cache 1066MHz 95W 3331 HC1 A2C4 Addl Intel Xeon Processor E5-4607 6C 2.2GHz 12MB Cache 1066MHz 95W 3331 HC1 A2C5 Addl Intel Xeon Processor E5-4610 6C 2.4GHz 15MB Cache 1333MHz 95W 3331 HC1 A2C7 Addl Intel Xeon Processor E5-4610 6C 2.4GHz 15MB Cache 1333MHz 95W 3331 HC1 A2C8 Addl Intel Xeon Processor E5-4617 6C 2.9GHz 15MB Cache 1600MHz 130W 3331 HC1 A2CA Addl Intel Xeon Processor E5-4617 6C 2.9GHz 15MB Cache 1600MHz 130W 3331 HC1 A2CB Addl Intel Xeon Processor E5-4640 8C 2.4GHz 20MB Cache 1600MHz 95W 3331 HC1 A2CD Addl Intel Xeon Processor E5-4640 8C 2.4GHz 20MB Cache 1600MHz 95W 3331 HC1 A2CE Addl Intel Xeon Processor E5-4620 8C 2.2GHz 16MB Cache 1333MHz 95W 3331 HC1 A2CG Addl Intel Xeon Processor E5-4620 8C 2.2GHz 16MB Cache 1333MHz 95W 3331 HC1 A2CH Addl Intel Xeon Processor E5-4650 8C 2.7GHz 20MB Cache 1600MHz 130W 3331 HC1 A2CK Addl Intel Xeon Processor E5-4650 8C 2.7GHz 20MB Cache 1600MHz 130W 3331 HC1 A2CL Addl Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB Cache 1600MHz 115W 3331 HC1 A2QV Addl Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB Cache 1600MHz 115W 3331 HC1 A2QW ServeRAID M5100 Series Enablement Kit for IBM Flex System x440 3331 HC1 A3DS ServeRAID M5100 Series IBM Flex System Flash Kit for x440 3331 HC1 A3DT ServeRAID M5100 Series SSD Expansion Kit for IBM Flex System x440 3331 HC1 A3DU
Single Entity Offerings (SEO)
SEO
Description number
IBM Flex System x440 Compute Node
7917F4U
7917F2U
7917D4U
7917D2U
7917C4U
7917C2U
7917B4U
7917B2U
7917A4U
7917A2U
Option SEOs The following are new unique option part numbers for IBM Flex System x440 Compute Node. SEO number Description 88Y6263 Intel Xeon Processor E5-4603 4C 2.0GHz 10MB Cache 1066MHz 95W 90Y9060 Intel Xeon Processor E5-4603 4C 2.0GHz 10MB Cache 1066MHz 95W 69Y3100 Intel Xeon Processor E5-4607 6C 2.2GHz 12MB Cache 1066MHz 95W 90Y9062 Intel Xeon Processor E5-4607 6C 2.2GHz 12MB Cache 1066MHz 95W 69Y3106 Intel Xeon Processor E5-4610 6C 2.4GHz 15MB Cache 1333MHz 95W 90Y9064 Intel Xeon Processor E5-4610 6C 2.4GHz 15MB Cache 1333MHz 95W 90Y9049 Intel Xeon Processor E5-4617 6C 2.9GHz 15MB Cache 1600MHz 130W 90Y9066 Intel Xeon Processor E5-4617 6C 2.9GHz 15MB Cache 1600MHz 130W 90Y9055 Intel Xeon Processor E5-4640 8C 2.4GHz 20MB Cache 1600MHz 95W 90Y9068 Intel Xeon Processor E5-4640 8C 2.4GHz 20MB Cache 1600MHz 95W 69Y3112 Intel Xeon Processor E5-4620 8C 2.2GHz 16MB Cache 1333MHz 95W 90Y9070 Intel Xeon Processor E5-4620 8C 2.2GHz 16MB Cache 1333MHz 95W 69Y3118 Intel Xeon Processor E5-4650 8C 2.7GHz 20MB Cache 1600MHz 130W 90Y9072 Intel Xeon Processor E5-4650 8C 2.7GHz 20MB Cache 1600MHz 130W 90Y9185 Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB Cache 1600MHz 115W 90Y9186 Intel Xeon Processor E5-4650L 8C 2.6GHz 20MB Cache 1600MHz 115W 46C9030 ServeRAID M5100 Series Enablement Kit for IBM Flex System x440 46C9031 ServeRAID M5100 Series IBM Flex System Flash Kit for x440 46C9032 ServeRAID M5100 Series SSD Expansion Kit for IBM Flex System x440 The following feature numbers are automatically added to the 5372-SWX HIPO order whenever one of the hardware system units is configured in an order. HIPO feature number Description 4284 7917-AC1 Routing Code 4285 7917-MC1 Routing Code
Industry Leading Quality, Support and Integrity
Quality Inspection Checklist
Before it leaves our facility, every used and refurbished item is thoroughly inspected by our certified technicians and undergoes our exclusive Quality Inspection Checklist to ensure 100% satisfaction guarantee.
Greentec Systems is a leading provider
For server, networking and storage equipment. We have an extensive array of inventory of IBM Servers & Storage, Sun Servers & Storage, Cisco Networking (Switches, Routers, Security), and NetApp Storage (disk shelves, disk drives, Filers, NearStore, NetCache). If you don’t see the item or product you require please contact us.
Have this equipment to sell?
Depending on the age and condition of the equipment, there is a very good likelihood that we will be able to offer you cash or trade-in credit for other IT hardware. If the equipment is very old we can also assist you with properly decommissioning that gear in the most environmentally friendly way possible.
Questions?
For more information please contact 888.333.7388, or fill out the quote from above. We’d love to hear from you.
