IBM BLADECENTER HX5
REQUEST A PRICE QUOTE:
This blade server supports a wide selection of processors and operating systems to allow a diverse workoad in this architecture.
- Form factor/height: Singlewide (30 mm) – double-wide (60 mm)
- Processor (max): Intel® Xeon® E7-4800 and E7-2800 processors; 6/8/10 cores, up to 2.67 GHz Up to 2 processors per single-wide HX5; scalable to 4 processors
- Number of processors (std/max): 1/2 (scalable to 4)
- Cache (max): Up to 30 MB per processor (10 core)
- Memory (max): 16 DDR-3 VLP DIMM slots, capacity up to 256 GB, per single-wide HX5 (scalable up to 640 GB max, at speeds up to 1067 MHz, via 40 DIMM slots, using a MAX5 expansion blade)
- Expansion slots: 1 CIOv slot (standard PCIe daughter card) and 1 CFFh slot (high-speed PCIe daughter card) for total of 8 ports of I/O to each blade, including 4 ports of high-speed I/O Scalable up to 16 ports of I/O in 4-socket, double-wide form factor
- Disk bays (total/hot swap): 2 non-hot-swap bays supporting solid-state drives per single-wide HX5
- Maximum internal storage: Up to 100 GB of solid-state storage per single-wide HX5 (with 50 GB SSDs)
- Network interface: Broadcom 5709S onboard NIC with dual Gigabit Ethernet ports with TOE
- RAID support: Optional RAID-0, -1, -1E
- Systems management: Integrated systems management processor
- Operating systems supported: Microsoft® Windows®, Red Hat Linux®, SUSE Linux, VMware
