HP ProLiant DL360p G8 GEN8 2x6C 2GHZ (E5-2620) 96GB P420i 1GB 670640-425 Server
REQUEST A PRICE QUOTE:
HP ProLiant DL360p G8 GEN8 2x6C 2GHZ (E5-2620) 96GB
P420i 1GB 670640-425 Server
- Product Description
- HP ProLiant DL360p Gen8 – Xeon E5-2620 2 GHz – 8 GB – 0 GB
- Type
- Server
- Form Factor
- Rack-mountable – 1U
- Localisation
- EMEA
- Server Scalability
- 2-way
- Processor
- 2 x Intel Xeon E5-2620 / 2 GHz ( 2.5 GHz ) ( 6-core )
- Cache Memory
- 15 MB L3 Cache
- Cache Per Processor
- 15 MB
- RAM
- 96 GB (installed) / 384 GB (max) – DDR3 SDRAM – 1333 MHz – PC3-10600
- Storage Controller
- RAID ( SATA 6Gb/s / SAS 6Gb/s ) – PCI Express 3.0 x8 ( Smart Array P420i with 1GB FBWC )
- Server Storage Bays
- Hot-swap 2.5″
- Hard Drive
- No HDD
- Optical Storage
- DVD-RW
- Card Reader
- Yes
- Graphics Controller
- Matrox G200
- Networking
- GigE
- Power
- AC 120/230 V ( 50/60 Hz )
- Power Redundancy
- Optional
- Dimensions (WxDxH)
- 43.5 cm x 69.9 cm x 4.3 cm
- Weight
- 14.5 kg
- Manufacturer Warranty
- 3 years warranty – on-site
Detail
General
- Type
- Server
- Recommended Use
- Small business, corporate business
- Product Form Factor
- Rack-mountable – 1U
- Server Scalability
- 2-way
- Front Accessible Bays Qty
- 1
- Hot-Swap Bays Qty
- 8
- Localisation
- EMEA
Processor / Chipset
- CPU
- Intel Xeon E5-2620 / 2 GHz
- Max Turbo Speed
- 2.5 GHz
- Number of Cores
- 6-core
- 64-bit Computing
- Yes
- CPU Qty
- 1
- Max CPU Qty
- 2
- CPU Upgradability
- Upgradable
- Chipset Type
- Intel C600
Cache Memory
- Installed Size
- L3 Cache – 15 MB
- Cache Per Processor
- 15 MB
RAM
- Installed Size
- 8 GB / 384 GB (max)
- Technology
- DDR3 SDRAM
- Memory Speed
- 1333 MHz
- Memory Specification Compliance
- PC3-10600
- Form Factor
- DIMM 240-pin
- Features
- Registered, HP SmartMemory
- Configuration Features
- 2 x 4 GB
- RAM Supported
- PC3-12800 – 384 GB – registered , PC3-10600 – 768 GB , PC3-10600 – 128 GB – unbuffered – Advanced ECC
Hard Drive
- Type
- No HDD
Storage Controller
- Type
- 1 x RAID – integrated – PCI Express 3.0 x8
- Controller Interface Type
- SATA 6Gb/s / SAS 6Gb/s
- Storage Controller Name
- Smart Array P420i with 1GB FBWC
- RAID Level
- RAID 0, RAID 1, RAID 10, RAID 50
- Buffer Size
- 1 GB
Optical Storage
- Type
- DVD-RW
Card Reader
- Type
- Card reader
- Supported Flash Memory Cards
- SD Memory Card
Monitor
- Monitor Type
- None.
Graphics Controller
- Type
- Integrated
- Graphics Processor
- Matrox G200
- Video Interfaces
- VGA
Networking
- Type
- Integrated
- Ethernet Ports
- 4 x Gigabit Ethernet
- Ethernet Controller
- HP 331FLR
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol
- IPMI 2.0, SMASH CLP
- Remote Management Controller
- Integrated Lights-Out 4
- Features
- Wake on LAN (WoL), PXE support
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)
Expansion / Connectivity
- Bays
- 1 (total) / 0 (free) x external 5.25″ x 1/2H , 8 (total) / 8 (free) x hot-swap 2.5″ SFF
- Slots
- 24 (total) / 22 (free) x DIMM 240-pin , 2 (total) / 1 (free) x CPU , 1 (total) / 1 (free) x PCIe 3.0 x16 – half-length, full-height , 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile
- Interfaces
- 1 x serial , 1 x VGA , 4 x LAN (Gigabit Ethernet) , 1 x HP iLO , 6 x USB 2.0 ( 2 front, 4 rear )
Miscellaneous
- Features
- Administrator password, power-on password, keyboard password, serial port I/O control, quick lock, 94% efficiency power supply
- Compliant Standards
- ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, BSMI CNS 13438
Power
- Device Type
- Power supply – hot-plug
- Power Redundancy
- Optional
- Power Redundancy Scheme
- 1+1 (with optional power supply)
- Installed Qty
- 1
- Max Supported Qty
- 2
- Nominal Voltage
- AC 120/230 V ( 50/60 Hz )
- Power Provided
- 460 Watt
- 80 PLUS Certification
- 80 PLUS Platinum
Operating System / Software
- OS Certified
- SuSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris
Dimensions & Weight
- Width
- 43.5 cm
- Depth
- 69.9 cm
- Height
- 4.3 cm
- Weight
- 14.5 kg
Environmental Parameters
- Min Operating Temperature
- 10 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 10 – 90% (non-condensing)
