Dell Cisco SFS M7000E InfiniBand Switch GN417 0GN417 for M1000E Blade Enclosure

The Cisco SFS M7000E switch (Figure 1) delivers an ideal combination of price and performance for customers seeking to minimize costs and maximize results with the Dell M1000e blade platform. The switch provides double-data-rate (DDR) InfiniBand connectivity to up to 16 server modules and provides 8 DDR InfiniBand uplink ports. Each DDR InfiniBand port can support 20 Gbps of fully nonblocking bandwidth to each port. The port-to-port latency through the switch is 140 nanoseconds (ns).

• Interconnects 16 Dell blade servers with auto-sensing single and double data rate (10-20 Gbps) capable port
• Provides less than 140 ns latency from port to port
• Allows expansion on demand with hot-pluggable switches
• Provides powered ports to enable flexible copper and optical interface configurations
• Offers non-blocking switch fabric configurations, with Dell M1000E’s multiple I/O module bays

The Cisco SFS M7000E switch provides high performance computing (HPC) customers with competitive advantage by minimizing costs and maximizing results.
