Also included:

• Rack Mount ears
• Power Cable

The Cisco Catalyst 3560-48TS switch is a next-generation fixed configuration, enterprise-class, Layer 3 switch that features a Fast Ethernet configuration to provide availability, security, and quality of service (QoS) to enhance network operations. The Cisco Catalyst 3560-48TS is an ideal access layer switch for small enterprise wiring closets or branch office environments that are using their LAN infrastructure for the deployment of new products and applications such as IP telephones, wireless access points, video surveillance, building management systems, and remote video kiosks.

Key Features

• 48 Ethernet 10/100 ports and 2 SFP-based Gigabit Ethernet ports
• 1RU fixed configuration, multilayer switch
• Enterprise-class intelligent services delivered to the network edge
• Advanced IP routing & QoS
• Standard Multilayer Software Image (SMI) installed
• Ease of use and deployment
• Superior Redundancy for Fault Backup
• Integrated Cisco IOS Software features for bandwidth optimization
• 8.8 Gbps switching fabric
• 4.4 Gbps maximum forwarding bandwidth at Layer 2 and Layer 3
• Forwarding rate based on 64-byte packets:6.6 Mpps
• 128-MB DRAM and 16-MB Flash memory
• Configurable up to 12,000 MAC addresses & 11,000 unicast routes
• Configurable up to 1000 IGMP groups and multicast routes

Customers can deploy network-wide intelligent services, such as advanced QoS, rate limiting, access control lists, multicast management, and high-performance IP routing – while maintaining the simplicity of traditional LAN switching. Embedded in the Cisco Catalyst 3560-48TS switch is the Cisco Cluster Management Suite (CMS) Software, which allows users to simultaneously configure and troubleshoot multiple Cisco Catalyst desktop switches using a standard Web browser. Cisco CMS Software provides configuration wizards that greatly simply the implementation of converged networks and intelligent network services.

The Cisco Catalyst 3560-48TS switch is available with either the IP Base or IP Services software images. The IP Base software includes advanced QoS, rate-limiting, ACLs, and basic routing and IPv6 functionality. The IP Services software provides a richer set of enterprise-class features, including advanced hardware-based IP unicast and IP Multicast routing as well as policy-based routing (PBR).

Memory

• Flash Memory : 16MB
• Memory Size : 128MB
• Memory Type : DRAM

Performance

• Width : 44.5cm
• Backplane : 17.6Gbps
• Mean Time Between Failure (MTBF) : 173,500 Hours
• Width : 44.5cm
• Width : 44.5cm
• Topology : Switched Fabric

Interfaces/Ports

• Console Ports : RJ-45-to-DB9 cable for PC connections
• Fixed Ports/Connectors : 48 x RJ-45
• Number of Fixed Ports : 48
• Fixed Port Speed : 10/100
• Fixed Port Connector : RJ-45
• GBIC Slots (Available) : 4 x SFP
• Number of Slots : 4
• Slot Type : SFP

Compliance

• Standards Compliance : IEEE 802.1s • IEEE 802.1w • IEEE 802.1x • IEEE 802.3ad • IEEE 802.3af • IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports • IEEE 802.1D Spanning-Tree Protocol • IEEE 802.1p CoS Prioritization • IEEE 802.1Q VLAN • IEEE 802.3 10BASE-T specification • IEEE 802.3u 100BASE-TX specification • IEEE 802.3ab 1000BASE-T specification • IEEE 802.3z 1000BASE-X specification

System

• Management Capabilities : Cisco IOS CLI support provides a common user interface and command set with all Cisco routers and Cisco Catalyst desktop switches. • Cisco Intelligent Power Management implements the IEEE 802.3af optional power classification features in addition to Cisco enhancements to enable the granular control of power delivery to each Power over Ethernet port. • Service Assurance Agent (SAA) support facilitates service-level management throughout the LAN. • Switching Database Manager templates for access, routing, and VLAN deployment scenarios allow the administrator to easily maximize memory allocation to the desired features based on deployment-specific requirements. • VLAN trunks can be created from any port, using either standards-based 802.1Q tagging or the Cisco Inter-Switch Link (ISL) VLAN architecture. • Up to 1024 VLANs per switch or stack and up to 128 spanning-tree instances per switch are supported. • Four thousand VLAN IDs are supported. • Voice VLAN simplifies telephony installations by keeping voice traffic on a separate VLAN for easier administration and troubleshooting. • Cisco VTP supports dynamic VLANs and dynamic trunk configuration across all switches. • Cisco Group Management Protocol server functions enable a switch to serve as the Cisco Group Management Protocol router for client switches. EMI is required. • IGMPv3 snooping provides fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors. • Remote Switch Port Analyzer (RSPAN) allows administrators to remotely monitor ports in a Layer 2 switch network from any other switch in the same network. • For enhanced traffic management, monitoring, and analysis, the Embedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events). • Layer 2 traceroute eases troubleshooting by identifying the physical path that a packet takes from source to destination. • All nine RMON groups are supported through a SPAN port, which permits traffic monitoring of a single port, a group of ports, or the entire stack from a single network analyzer or RMON probe. • Domain Name System (DNS) provides IP address resolution with user-defined device names. • Trivial File Transfer Protocol (TFTP) reduces the cost of administering software upgrades by downloading from a centralized location. • Network Timing Protocol (NTP) provides an accurate and consistent timestamp to all intranet switches.
• Certifications : UL to UL 60950, Third Edition • C-UL to CAN/CSA C22.2 No. 60950-00, Third Edition • TUV/GS to EN 60950:2000 • CB to IEC 60950 with all country deviations • NOM to NOM-019-SCFI • CE Marking
• Security : Cisco Identity Based Networking Services (IBNS) in the Catalyst 3560 Series prevents unauthorized access and helps ensure that users get only their designated privileges. It provides the ability to dynamically administer granular levels of network access. Using the 802.1x standard and the Cisco Access Control Server (ACS), users can be assigned a VLAN or an ACL upon authentication, regardless of where they connect to the network. This setup allows IT departments to enable strong security policies without compromising user mobility-and with minimal administrative overhead.

Electrical

• AC Voltage Range : 100 to 240VAC
• Power over Ethernet Supported : No

Environmental

• Noise Level (full operating mode) : 32dbA
• Operating Humidity : 10 to 85%
• Operating Temperature : 0 to 45°C

Physical

• Form Factor : Network Switch
• Depth : 37.7cm
• Height : 4.4cm
• Weight : 6.0kg
• Width : 44.5cm
