Cisco UC520 24-User Voice VoIP Router

Included

• 1 x Cisco UC520 UC520-24U-4BRI-K9 24-User Voice VoIP Router

Cisco Unified Communications 500 Series for Small Business, a critical part of the Cisco Smart Business Communications System, is a unified communications solution for small businesses that provides voice, data, voicemail, Automated Attendant, video, security, and wireless capabilities while integrating with existing desktop applications such as calendar, e-mail, and customer relationship management (CRM) programs. This easy-to-manage platform uses business-class, proven unified communications technologies to full advantage and supports flexible deployment models based on your needs – a wide array of IP phones, public switched telephone network (PSTN) interfaces, and Internet connectivity.

Specifications

General

• Device Type: VoIP gateway
• Height (Rack Units): 2U
• Installed Modules Qty (Max): 1 ( 1 )
• Width: 44.5 cm
• Depth: 35.6 cm
• Height: 8.9 cm
• Weight: 6.6 kg

Networking

• Form Factor: Rack-mountable
• Connectivity Technology: Wired
• Data Link Protocol: Ethernet, Fast Ethernet
• Switching Protocol: Ethernet
• Remote Management Protocol: SNMP
• Features: Firewall protection, MAC address filtering
• Encryption Algorithm: LEAP, PEAP, TKIP, WPA, WPA2
• Authentication Method: RADIUS, Radio Service Set ID (SSID), Extensible Authentication Protocol (EAP)
• Compliant Standards: IEEE 802.3af, IEEE 802.1x

IP Telephony

• VoIP Protocols: H.323, SCCP, SIP
• Voice Codecs: G.711, G.729a
• Telephony Interfaces: 8 line (FXO), 4 phone (FXS)
• IP Telephony Features: Call waiting, call hold, call transfer

Expansion / Connectivity

• Expansion Slot(s): 1 (total) / 0 (free) x VIC
• Interfaces: 8 x phone line – FXO – RJ-11 ¦ 4 x phone line – FXS – RJ-11 ¦ 8 x network / power – Ethernet 10Base-T/100Base-TX – RJ-45 ¦ 1 x network – Ethernet 10Base-T/100Base-TX – RJ-45
• WAN ) ¦ 1 x network – Ethernet 10Base-T/100Base-TX – RJ-45 ¦ 1 x audio – mini-phone 3.5mm ¦ 1 x management – console

Miscellaneous

• Compliant Standards: CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC Part 15, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11, EN300-386, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1

Power

• Power Over Ethernet (PoE) Supported: Yes
• Power Device: Power supply – internal
• Voltage Required: AC 120/230 V ( 50/60 Hz )

Environmental Parameters

• Min Operating Temperature: 0 °C
• Max Operating Temperature: 40 °C
• Humidity Range Operating: 10 – 85%
