Cisco Small Business SR224 24-Port 10/100 Ethernet Unmanaged Switch

Included:

• 1 x Cisco Small Business SR224 24-Port 10/100 Ethernet Switch Unmanaged Switch
• 1 x Power Supply

With its advanced switching technology, the Cisco® SR224 24-Port 10/100 Switch with a 13-Inch
Chassis (Figure 1) will boost your network performance with much more than just full-duplex data
transfer and dedicated bandwidth. It features nonblocking, wire-speed switching that forwards
packets as fast as your network can deliver them. Also included are Address Learning and Aging
to prevent data transfer errors and Data Flow Control to help prevent packet collisions.

Features
? Ideal for integrating your 10BASE-T and 100BASE-TX network hardware
? Twenty-four 10/100 ports provide dedicated bandwidth in half- or full-duplex mode
? Switched 10/100 ports run at up to 200 Mbps in full-duplex mode
? Each port supports automatic medium dependent interface (MDI) and MDI crossover (MDIX)
cable detection

Specifications:
Standards IEEE 802.3, IEEE 802.3u
Ports Twenty-four 10/100 RJ-45
Cabling type Category 5 Ethernet or better
LEDs System, 1 through 24
Range 328 feet
Security features Security slot
Environmental
Dimensions
W x H x D
11 x 1.75 x 9.45 in.
(279 x 45 x 240 mm)
Unit weight 3.31 lb (1.5 kg)
Power 100V ~ 240V AC, internal 3.3V/5A
Certification FCC Class B, CE
Operating temperature 32º to 104ºF (0º to 40ºC)
Storage temperature -40º to 158ºF (-40º to 70ºC)
Operating humidity 20% to 95% noncondensing
Storage Humidity 5% to 90% noncondensing
