Cisco Small Business SFE2010 48-Port Fast Ethernet Network Switch

Specifications:

• Product Description: Cisco Small Business Managed Switch SFE2010 – switch – 48 ports
• Device Type: Switch – stackable
• Form Factor: Rack-mountable – 1U
• Ports Qty: 48 x Ethernet 10Base-T, Ethernet 100Base-TX
• Data Transfer Rate: 100 Mbps
• Data Link Protocol: Ethernet, Fast Ethernet
• Auxiliary Network Ports: 2×10/100/1000Base-T
• Empty Slots: 2 x SFP (mini-GBIC)
• Remote Management Protocol: SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH
• Communication Mode: Half-duplex, full-duplex
• Features: Auto-sensing per device, DHCP support, auto-negotiation, BOOTP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DoS attack prevention, port mirroring, Weighted Round Robin (WRR) queuing, MAC address filtering, Broadcast Storm Control, IPv6 support, firmware upgradable, SNTP support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
• Max Units In A Stack: 4
• Routing Protocol: IGMPv2, IGMP
• MAC Address Table Size: 8K entries
• Status Indicators: Link activity, port transmission speed, power, link OK, Unit ID
• Interfaces: 48 x network node – Ethernet 10Base-T/100Base-TX – RJ-45, 2 x network host – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45, 1 x management – console
• Encryption Algorithm: MD5
• Authentication Method: Secure Shell (SSH), RADIUS
• Compliant Standards: CE, UL 60950, CSA C22.2, FCC CFR47 Part 15
• Power: AC 120/230 V (50/60 Hz)
• Dimensions (WxDxH): 17.3 in x 14.8 in x 1.7 in
• Weight: 10.8 lbs

Boot Log:

Boot1 Checksum Test………………………….PASS

Boot2 Checksum Test………………………….PASS

Flash Image Validation Test…………………..PASS

BOOT Software Version 2.0.0.03 Built  18-May-2009  09:01:25

Networking device with 88F5181 CPU based on ARM926EJ-S core.

Autoboot in 2 seconds – press RETURN or Esc. to abort and enter prom.

Preparing to decompress…

 100%

Decompressing SW from image-1

 100%

OK

Running from RAM…

 *********************************************************************

*** Running  SW  Ver. 3.0.0.17  Date  08-Nov-2009  Time  12:59:16 ***

*********************************************************************

HW version is 00.00.01

Base Mac address is: 68:ef:bd:1b:08:ff

Dram size is  : 128M bytes

Dram first block size is  : 106496K bytes

Dram first PTR is  : 0x1800000

Dram second block size is  : 0K bytes

Dram second PTR is  : 0x8000000

Flash size is: 32M

08-Nov-2009 12:59:24 %CDB-I-LOADCONFIG: Loading running configuration.

08-Nov-2009 12:59:24 %CDB-I-LOADCONFIG: Loading startup configuration.

Device configuration:

Slot 1 – SFE2010 HW Rev. 1

CPLD revision: 5

————————————

— Unit Number 1                  —

————————————

08-Nov-2009 12:59:38 %INIT-I-InitCompleted: Initialization task is completed

>

———————————-

— Unit Number 1  Master Enabled —

———————————–

Tapi Version: v1.3.3.1

Core Version: v1.3.3.1

08-Nov-2009 12:59:41 %SNMP-I-CDBITEMSNUM: Number of running configuration items loaded: 0

08-Nov-2009 12:59:41 %SNMP-I-CDBITEMSNUM: Number of startup configuration items loaded: 0

>08-Nov-2009 12:59:41 %Stack-I-STCK-CFG-CHNG: Configuration changed: chain
