Cisco SFS7000D-SK9  24 Port Infiniband Managed Server Switch

INCLUDED

• 1 x  24 Port Infiniband Managed Server Switch With 2 x Power Supply’s
• 1 x Rail Kit For Rack mounting unit in a server cabinet

DESCRIPTION

SFS 7000D InfiniBand Server Switch sets the standard for cost-effective, low-latency, 4X DDR and SDR

InfiniBand switching for building high-performance clusters.

High-performance computing (HPC) applications that solve complex, computationally intensive problems are widely deployed within

academic and research communities and enterprises because they deliver significant business benefits. An important enabler for the

broad adoption of HPC applications is the practice of clustering multiple industry-standard servers using a high-speed network to

provide supercomputer performance, at a fraction of the cost of traditional supercomputers.

PRODUCT OVERVIEW

The Cisco SFS 7000D delivers an ideal combination of price, performance, and packaging for building high-performance server clusters

of all sizes. The Cisco SFS 7000D provides 24 InfiniBand 4X ports that can operate in double data rate (DDR) or single data

rate (SDR) mode, which delivers 20- or 10-Gbps server connectivity respectively. The Cisco SFS 7000D is a fully nonblocking, 960-Gbps

cross-sectional bandwidth switch fabric that has less than 200 nanoseconds (ns) of port-to-port latency. In common with the Cisco SFS

7000P, the Cisco SFS 7000D comes with the embedded Cisco InfiniBand Subnet Manager, which is capable of running large clusters in

a single, compact 1 rack unit (1RU) chassis.

BENEFITS

The Cisco SFS 7000D provides the following customer benefits:

• Autosensing 24 InfiniBand 4X 20-Gbps DDR or 10-Gbps SDR Interfaces
• Superior price and performance for building HPC clusters
• Ideal form factor for top-of-rack switch for small HPC clusters or as part of a larger HPC cluster
• Embedded Cisco InfiniBand Subnet Manager facilitates convenient “plug-and-play” operation for small clusters that can scale to
• support large HPC clusters
• InfiniBand 1.2-compliant
• Easy configuration, monitoring, and maintenance in-band and out-of-band

FEATURES

• The Cisco SFS 7000D provides the following features:
• High-performance, low-latency switched server interconnect
• 24 nonblocking, full duplex InfiniBand 4X DDR (20 Gbps) or SDR (10 Gbps) autosensing ports
• Supports DDR-to-SDR switching capability for investment protection and higher server densities
• Fully redundant power and cooling, with hot-swappable field replaceable units (FRUs)
• Command-line interface (CLI), Web, and Java-based systems management options
• 1RU stackable architecture, with included 4-post rack mounting kit suitable for rack-based shipping
• Single hop, less than 200 ns cut-through latency port to port
• Full bisectional bandwidth for all 24 ports (960 Gbps)
• Optional standalone, high-performance Cisco Subnet Manager
• Powered ports to enable flexible copper and optical interface configurations

SPECIFICATIONS
