Cisco Pix-515E Restricted Network Security Appliance Firewall





The Cisco PIX 515E Firewall is an enhanced version of the widely popular Cisco PIX 515 platform, providing industry-leading stateful firewall and IP Security (IPSec) virtual private networking (VPN) services. Designed for small and medium businesses, as well as enterprise remote offices, the Cisco PIX 515E features increased processing power and integrated, hardware-based IPSec acceleration (certain models) delivering even more robust performance for high-throughput security requirements. The Cisco PIX 515E “Restricted” model provides an excellent value for organizations looking for robust Cisco PIX Firewall services with minimal interface density and VPN throughput requirements.

CISCO SYSTEMS PIX FIREWALL

Embedded BIOS Version 4.3.207 01/02/02 16:12:22.73

Compiled by morlee



128 MB RAM

PCI Device Table.

Bus Dev Func VendID DevID Class              Irq

00  00  00   8086   7192  Host Bridge

00  07  00   8086   7110  ISA Bridge

00  07  01   8086   7111  IDE Controller

00  07  02   8086   7112  Serial Bus         9

00  07  03   8086   7113  PCI Bridge

00  0D  00   8086   1209  Ethernet           11

00  0E  00   8086   1209  Ethernet           10

Cisco Secure PIX Firewall BIOS (4.2) #0: Mon Dec 31 08:34:35 PST 2001

Platform PIX-515E

System Flash=E28F128J3 @ 0xfff00000

Use BREAK or ESC to interrupt flash boot.

Use SPACE to begin flash boot immediately.

Reading 123392 bytes of image from flash.

PIX Flash Load Helper

Initializing flashfs…

flashfs[0]: 10 files, 3 directories

flashfs[0]: 0 orphaned files, 0 orphaned directories

flashfs[0]: Total bytes: 16128000

flashfs[0]: Bytes used: 13338112

flashfs[0]: Bytes available: 2789888

flashfs[0]: Initialization complete.

Booting first image in flash

Launching image flash:/pix704.bin

128MB RAM

Total NICs found: 2

mcwa i82559 Ethernet at irq 11  MAC: 0015.2b05.8acc

mcwa i82559 Ethernet at irq 10  MAC: 0015.2b05.8acb

BIOS Flash=am29f400b @ 0xd8000

Initializing flashfs…

flashfs[7]: 10 files, 3 directories

flashfs[7]: 0 orphaned files, 0 orphaned directories

flashfs[7]: Total bytes: 16128000

flashfs[7]: Bytes used: 13338112

flashfs[7]: Bytes available: 2789888

flashfs[7]: flashfs fsck took 14 seconds.

flashfs[7]: Initialization complete.

Need to burn loader….

Erasing sector 0…[OK]

Burning sector 0…[OK]

pixfirewall> show version

Cisco PIX Security Appliance Software Version 7.0(4)

Device Manager Version 5.0(1)

Compiled on Thu 13-Oct-05 21:43 by builders

System image file is “flash:/pix704.bin”

Config file at boot was “startup-config”

pixfirewall up 39 secs

Hardware:   PIX-515E, 128 MB RAM, CPU Pentium II 433 MHz

Flash E28F128J3 @ 0xfff00000, 16MB

BIOS Flash AM29F400B @ 0xfffd8000, 32KB

0: Ext: Ethernet0           : address is 0015.2b05.8acb, irq 10

1: Ext: Ethernet1           : address is 0015.2b05.8acc, irq 11

Licensed features for this platform:

Maximum Physical Interfaces : 3

Maximum VLANs               : 10

Inside Hosts                : Unlimited

Failover                    : Disabled

VPN-DES                     : Enabled

VPN-3DES-AES                : Enabled

Cut-through Proxy           : Enabled

Guards                      : Enabled

URL Filtering               : Enabled

Security Contexts           : 0

GTP/GPRS                    : Disabled

VPN Peers                   : Unlimited

This platform has a Restricted (R) license.

Serial Number: 809313335
