Cisco Nexus 5010 N5K-C5010P-BF 20-Port 10Gb Switch

Included

• 1 x Cisco Nexus 5010 N5K-C5010P-BF 20-Port 10Gb Switch
• 2 x 550w Power Supplies N5K-PAC-550W
• 2 x Fans N5K-C5010-FAN

The Cisco Nexus 5010 is a 1RU, 10 Gigabit Ethernet, FCoE, and Fiber Channel switch providing more than 520-Gbps throughput with very low latency. It has 20 fixed 10 Gigabit Ethernet and FCoE SFP+ ports. The first 8 fixed ports are dual speed, supporting both 10 Gigabit Ethernet and Gigabit Ethernet in hardware and providing a smooth migration path to 10 Gigabit Ethernet. One expansion module slot can be configured to support up to 6 additional 10 Gigabit Ethernet and FCoE SFP+ ports, up to 8 4Gbps SFP Fiber Channel switch ports, up to 6 8Gbps SFP+ Fiber Channel switch ports or a combination of 4 additional 10 Gigabit Ethernet and FCoE SFP+ ports with 4 additional 4/2/1-Gbps Fiber Channel switch ports. The switch has a serial console port and an out-of-band 10/100/1000-Mbps Ethernet management port. The switch is powered by 1+1 redundant, hot-pluggable power supplies and 1+1 redundant, hot-pluggable fan modules to provide highly reliable front-to-back cooling.

Features

• Layer 2 hardware forwarding at 520 Gbps or 386.9 mpps
• MAC address table entries: 16,000
• Low-latency cut-through design that provides predictable, consistent traffic latency regardless of packet size, traffic pattern, or enabled features on 10 Gigabit Ethernet interfaces
• Line-rate traffic throughput on all ports
• 20 fixed 10 Gigabit Ethernet and FCoE Ports (ports 1 to 8 are Gigabit Ethernet and 10 Gigabit Ethernet); additional interfaces through one expansion module

Standards

• IEEE 802.1D: Spanning Tree Protocol
• IEEE 802.1p: CoS prioritization
• IEEE 802.1Q: VLAN tagging
• IEEE 802.1s: Multiple VLAN instances of Spanning Tree Protocol
• IEEE 802.1w: Rapid reconfiguration of Spanning Tree Protocol
• IEEE 802.3: Ethernet
• IEEE 802.3ad: LACP with fast timers
• IEEE 802.3ae: 10 Gigabit Ethernet
• SFF 8431 SFP+ CX1 support
• RMON
• Jumbo Frames: 9216 bytes
• Primary Port Speed:10/100/1000Mbps + 10 Gigabit

Security

• Ingress ACLs (standard and extended) on Ethernet and virtual Ethernet ports
• Standard and extended Layer 2 ACLs: MAC addresses, protocol type, etc.
• Standard and extended Layer 3 to 4 ACLs: IPv4 and v6, Internet Control Message Protocol (ICMP), TCP, User Datagram Protocol (UDP), etc.
• VLAN-based ACLs (VACLs)
• Port-based ACLs (PACLs)
• Named ACLs
• ACL logging and statistics
• Optimized ACL distribution
• SNMP: Yes
• QoS: Yes
• LACP: Yes
• Layer: 1
• Module Support: Yes
• VLAN Support: Yes

Power

• Typical operating power: 350W
• Maximum power: 450W
• Input voltage: 100 to 240 VAC
• Frequency: 50 to 60 Hz
• Efficiency: 88 to 90%
• Heat dissipation: 1536 BTU/hr

Dimensions

• 1.72 x 17.3 x 30.0 in.(4.4 x 43.9 x 76.2 cm)
