Cisco Catalyst WS-C2960-24PC-S 24Port SI PoE-24 Ethernet Rack Mountable Switch

Includes

• 1 x Cisco Catalyst WS-C2960-24PC-S V03 24Port Managed Ethernet Rack Mountable Switch

Description

Cisco Catalyst 2960 series switches with LAN Lite software are fixed-configuration, standalone switches that provide desktop Fast Ethernet connectivity for entry-level wiring closet and small branch-office networks. These switches simplify the migration from non-intelligent hubs and unmanaged switches to a fully scalable managed network.

Cisco Catalyst 2960 series switches have lower cost of ownership with features such as intelligent switch configuration using Auto Smart Ports, installation with Auto Install and enhanced troubleshooting to facilitate ease of use. Comprehensive management tools provide ongoing management and monitoring of switches. Services integrating voice, video, and wireless applications are possible using the Cisco Catalyst 2960 Series LAN Lite Switches. Power over Ethernet (POE) and quality of service (QoS) provide comprehensive service delivery for entry-level customers. Security capabilities that are pervasive in the network are critical for secure operations, and end-to-end security is obtained using the Cisco Catalyst 2960 Series Switches with LAN Lite software. An array of Cisco security solutions is available, including Cisco Clean Access NAC-based solutions.

Features

• Autosensing
• Autosensing on each 10/100 port detects the speed and duplex of the attached device and automatically configures the port for 10- or 100-Mbps operation, easing switch deployment in mixed 10- and 100-Mbps environments.
• Automatic medium-dependent interface crossover
• Automatic medium-dependent interface crossover (Auto-MDIX) automatically adjusts transmit and receive pairs if an incorrect cable type (crossover or straight-through) is installed on a copper port.
• Multifunction LEDs
• Multifunction LEDs per port for port status; half-duplex and full-duplex mode; and 10BASE-T, 100BASE-TX, and 1000BASE-T indication as well as switch-level status LEDs for the system and a redundant power supply provide a comprehensive and convenient visual management system.

Specifications

• Device Type Switch – 24 ports – Managed
• Enclosure Type Rack-mountable 1U
• Interfaces Fast Ethernet
• Ports 24 x 10/100 (PoE) + 2 x combo Gigabit SFP
• Power Over Ethernet (PoE) PoE
• Performance Switching capacity : 16 Gbps
• Forwarding performance (64-byte packet size) : 6.5 Mpps
• MAC Address Table Size 8K entries
• Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH-2
• Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP)
