Cisco 3845 – 2 Port Gigabit Wired Integrated Service Router – Rack Mountable

Included:

• 1 x Cisco 3845 – 2 Port Gigabit Wired Integrated Service Router With Rack Mount Ears

Description

The Cisco 3845 Integrated Services Router is part of the Cisco 3800 Integrated Services Router Series which complements the Integrated Services Router Portfolio.

The Cisco 3845 Integrated Services Router provides the following support:

• Wire-speed performance for concurrent services such as security and voice, and advanced services at full T3/E3 rates
• Enhanced investment protection through increased performance and modularity
• Enhanced investment protection through increased modularity
• Increased density through High-Speed WAN Interface Card Slots (four)
• Enhanced Network Module Slot
• Support for over 90 existing and new modules
• Support for majority of existing AIMs, NMs, WICs, VWICs, and VICs
• Integrated GE ports with copper and fiber support
• Optional Layer 2 switching support with Power over Ethernet (PoE) (as an option) , supports the 36-port Cisco EtherSwitch module (NMD-36ESW)

• Security
  • On-board encryption
  • Support of up to 2500 VPN tunnels with the AIM-HPII-PLUS Module
  • Antivirus defense support through Network Admission Control (NAC)
  • Intrusion Prevention as well as stateful Cisco IOS Firewall support and many more essential security features

• Voice
  • Analog and digital voice call support
  • Optional voice mail support
  • Optional support for Cisco CallManager Express for local call processing in stand alone business for up to 240 IP Phones
  • Optional support for Survivable Remote Site Telephony support for local call processing in small enterprise branch offices for up to 720 IP phones

Boot Log

*Jan 10 15:40:56.199: %SYS-5-RELOAD: Reload requested by console. Reload Reason: Reload Command.

System Bootstrap, Version 12.4(13r)T15, RELEASE SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Copyright (c) 2010 by cisco Systems, Inc.

Total memory size = 512 MB – DIMM0 = 512 MB, DIMM1 = 0 MB

c3845 platform with 524288 Kbytes of main memory

Main memory is configured to 72/0(dimm 0/1) bit mode with ECC enabled

Readonly ROMMON initialized

program load complete, entry point: 0x8000f000, size: 0xcb40

program load complete, entry point: 0x8000f000, size: 0xcb40

program load complete, entry point: 0x80010000, size: 0x20f7a30

Self decompressing the image :

Smart Init is enabled

smart init is sizing iomem

  ID            MEMORY_REQ                 TYPE

00042C          0X010D78F3 C3845 motherboard

                0X00280000 OIR memory

                0X00288860 DSP SIMM

                0X000021B8 Onboard USB

                0X00660670 public buffer pools

                0X0078F000 public particle pools

TOTAL:          0X023D197B

Router>enable

Router#show version

Cisco IOS Software, 3800 Software (C3845-SPSERVICESK9-M), Version 12.4(25b), RELEASE SOFTWARE (fc1)

Technical Support: http://www.cisco.com/techsupport

Copyright (c) 1986-2009 by Cisco Systems, Inc.

Compiled Wed 12-Aug-09 15:53 by prod_rel_team

ROM: System Bootstrap, Version 12.4(13r)T15, RELEASE SOFTWARE (fc1)

Router uptime is 0 minutes

System returned to ROM by reload at 15:40:55 UTC Fri Jan 10 2014

System image file is “flash:c3845-spservicesk9-mz.124-25b.bin”

Cisco 3845 (revision 1.0) with 487424K/36864K bytes of memory.

Processor board ID FCZ145121BK

2 Gigabit Ethernet interfaces

DRAM configuration is 64 bits wide with parity enabled.

479K bytes of NVRAM.

126976K bytes of ATA System CompactFlash (Read/Write)
