Cisco 2821 2-Port Modular Gigabit Ethernet 2U Network Router – CCNA CCNP CCIE

Cisco 2821 2-Port Modular Gigabit Ethernet 2U Network Router - CCNA CCNP CCIE Cisco 2821 2-Port Modular Gigabit Ethernet 2U Network Router – CCNA CCNP CCIE 360710971001 e1538958263647

REQUEST A PRICE QUOTE:

    Name*

    Phone

    Details*

    Cisco 2821 2-Port Modular Gigabit Ethernet 2U Network Router

    Included

    • 1 x Cisco 2801 2-Port Modular Gigabit Ethernet 2U Network Router CISCO2821

    The Cisco 2800 Series of integrated services routers intelligently embed data, security, and voice services into a single, resilient system for fast, scalable delivery of mission-critical business applications. The unique integrated systems architecture of the Cisco 2800 Series delivers maximum business agility and investment protection.The Cisco 2800 Series comprises four new platforms: the Cisco 2801, the Cisco 2811, the Cisco 2821, and the Cisco 2851. The Cisco 2800 Series features the ability to deliver multiple high-quality simultaneous services at wire speed up to multiple T1/E1/xDSL connections. The routers offer embedded encryption acceleration and on the motherboard voice digital-signal-processor (DSP) slots; intrusion prevention system (IPS) and firewall functions; optional integrated call processing and voice mail support; high-density interfaces for a wide range of connectivity requirements; and sufficient performance and slot density for future network expansion requirements and advanced applications.

    Specifications

    General

    • Manufacturer Part Number: CISCO2821
    • Product Type: Cisco 2821 Router
    • Form Factor: External – modular – 2U
    • Dimensions (WxDxH): 43.8 cm x 41.7 cm x 8.9 cm
    • Weight: 11.4 kg
    • DRAM Memory: 512 MB (installed) / 1 GB (max)
    • Flash Memory: 128 MB (installed) / 256 MB (max)
    • Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
    • Network / Transport Protocol: IPSec
    • Remote Management Protocol: SNMP 3, HTTP, SSH-2
    • Features: Cisco IOS IP Base , firewall protection, hardware encryption, VPN support, MPLS support, URL filtering
    • Power: AC 120/230 V (50/60 Hz)
    Boot Log
    System Bootstrap, Version 12.4(13r)T, RELEASE SOFTWARE (fc1)
    Technical Support: http://www.cisco.com/techsupport
    Copyright (c) 2006 by cisco Systems, Inc.

    Initializing memory for ECC
    .
    c2821 platform with 262144 Kbytes of main memory
    Main memory is configured to 64 bit mode with ECC enabled


    Readonly ROMMON initialized
    program load complete, entry point: 0x8000f000, size: 0xcb80
    program load complete, entry point: 0x8000f000, size: 0xcb80

    program load complete, entry point: 0x8000f000, size: 0x3584e04
    Self decompressing the image : ###################################################################[OK]

    Smart Init is disabled. IOMEM set to: 10

    Using iomem percentage: 10

    Cisco IOS Software, 2800 Software (C2800NM-ADVIPSERVICESK9-M), Version 12.4(20)YA3, RELEASE SOFTWARE (fc2)

    Installed image archive
    Cisco 2821 (revision 49.46) with 237568K/24576K bytes of memory.
    Processor board ID FCZ131170Q0
    2 Gigabit Ethernet interfaces
    1 Virtual Private Network (VPN) Module
    DRAM configuration is 64 bits wide with parity enabled.
    239K bytes of non-volatile configuration memory.
    126976K bytes of ATA CompactFlash (Read/Write)

    Router>enable
    Router#show version
    Cisco IOS Software, 2800 Software (C2800NM-ADVIPSERVICESK9-M), Version 12.4(20)YA3, RELEASE SOFTWARE (fc2)
    Technical Support: http://www.cisco.com/techsupport
    Copyright (c) 1986-2009 by Cisco Systems, Inc.
    Compiled Fri 03-Apr-09 19:21 by prod_rel_team

    ROM: System Bootstrap, Version 12.4(13r)T, RELEASE SOFTWARE (fc1)

    Router uptime is 3 minutes
    System returned to ROM by reload at 12:06:33 UTC Fri Jan 17 2014
    System image file is “flash:c2800nm-advipservicesk9-mz.124-20.YA3.bin”


    Cisco 2821 (revision 53.51) with 237568K/24576K bytes of memory.
    Processor board ID FCZ131170Q0
    2 Gigabit Ethernet interfaces
    1 Virtual Private Network (VPN) Module
    DRAM configuration is 64 bits wide with parity enabled.
    239K bytes of non-volatile configuration memory.
    126976K bytes of ATA CompactFlash (Read/Write)

    Configuration register is 0x2102
