Cisco 2621XM 2-Port Network Router

Included

• 1 x Cisco 2621XM Network Router

The Cisco 2600XM models are based on the current Cisco 2600 platform architecture, and extend the performance by as much as 33%. These models also increase default platform memory and provide increases in memory capacity at the same price points when compared to the current Cisco 2600 models. The XM functionality provides the same proven technology of the current Cisco 2600 Series platforms, including Cisco IOS software mainline feature support and the modularity of Network Modules (NMs), WAN Interface Cards (WICs) and Advanced Integration Modules (AIMs). Enterprises considering the Cisco 2600 for branch office applications should now regard the Cisco 2600XM as the preferential platform for delivering high-performing, flexible solutions to branch and remote offices.

Specifications

General

• Device Type: Router
• Form Factor: Rack-mountable – modular
• Installed Modules Qty (Max): 0 (installed) / 4 (max)
• Width: 17.5 in
• Depth: 11.8 in
• Height: 1.7 in
• Weight: 10.4 lbs

Processor

• Type: 1 x Motorola MPC860 50 MHz RISC
• Max Supported Qty: 1

Memory

• RAM: 128 MB (installed) / 256 MB (max)
• Flash Memory: 32 MB (installed) / 48 MB (max)

Networking

• Connectivity Technology: Wired
• Data Transfer Rate: 100 Mbps
• Data Link Protocol: Ethernet, Fast Ethernet
• Network / Transport Protocol: TCP/IP, AppleTalk, UDP/IP, IP/IPX
• Routing Protocol: OSPF, BGP
• Remote Management Protocol: RMON
• Features: Modular design, IP-routing, Appletalk-routing, IPX-routing, NAT support, manageable
• Compliant Standards: IEEE 802.3, IEEE 802.3u

Expansion / Connectivity

• Expansion Slots Total (Free): 4 ( 4 ) x expansion slot ¦ 2 ( 1 ) x memory ¦ 1 ( 0 ) x memory
• Interfaces: 2 x network – Ethernet 10Base-T/100Base-TX – RJ-45 – 2 ¦ 1 x management – console – RJ-45 – 1 ¦ 1 x network – auxiliary – RJ-45 – 1

Miscellaneous

• Authentication Method: RADIUS
• Compliant Standards: FCC Class A certified, UL, VCCI

Power

• Power Device: Power supply – internal
• Voltage Required: -38 – -75 V
• Power Provided: 72 Watt
• Compliant Standards: UL, IEC 61000-3-3, IEC 61000-3-2

Environmental Parameters

• Min Operating Temperature: 32 °F
• Max Operating Temperature: 104 °F
• Humidity Range Operating: 5 – 95%
