Cisco 2611XM 2-Port Network Router

Included

• 1 x Cisco 2611XM Network Router

The Cisco 2600XM models are based on the current Cisco 2600 platform architecture, and extend the performance by as much as 33%. These models also increase default platform memory and provide increases in memory capacity at the same price points when compared to the current Cisco 2600 models. The XM functionality provides the same proven technology of the current Cisco 2600 Series platforms, including Cisco IOS software mainline feature support and the modularity of Network Modules (NMs), WAN Interface Cards (WICs) and Advanced Integration Modules (AIMs). Enterprises considering the Cisco 2600 for branch office applications should now regard the Cisco 2600XM as the preferential platform for delivering high-performing, flexible solutions to branch and remote offices.

Specifications

• General
• Device Type: Router
• Enclosure Type: Desktop – Modular
• Data Link Protocol: Ethernet, Fast Ethernet
• Data Transfer Rate: 100 Mbps
• Remote Management Protocol: RMON
• Features: VLAN support, Manageable, Modular design, NAT support
• Compliant Standards: IEEE 802.1Q
• Expansion / Connectivity
• Interfaces Management: 1 x Console – RJ-45, 1 x Auxiliary – RJ-45, 2 x Ethernet 10Base-T/100Base-TX – RJ-45
• Expansion Slot(s): 4 (total) / 4 (free) x Expansion slot, 2 (total) / 1 (free) x Memory – DIMM 100-pin, 1 (total) / 1 (free) x Memory – SIMM 80-pin

Networking

• onnectivity Technology: Wired
• Network / Transport Protocol: IP/IPX, AppleTalk, UDP/IP, TCP/IP
• Status Indicators: Link activity, Port status, Power
• Routing Protocol: BGP, OSPF

Power

• Power: Device Power supply – Internal

Miscellaneous

• Width: 17.5 in
• Depth: 11.8 in
• Height: 1.7 in
• Compliant Standards NOM, VCCI, VCCI Class A ITE, EN 60950, UL
• Weight: 10.4 lbs
• Authentication Method: RADIUS

Memory

• Memory / RAM: 96 MB 128 MB SDRAM DIMM 100-pin
• Memory / Flash: 32 MB 48 MB Flash

Processor

• Type: 1 x Motorola MPC860P 40 MHz

Environmental Parameters

• Min Operating Temperature: 32 °F
• Max Operating Temperature: 104 °F
• Humidity Range: Operating 5 – 95%
